Zero-field identification and control of hydrogen-related electron-nuclear spin registers in diamond

This paper introduces zero-field electron-nuclear spin control protocols to characterize unknown defects in diamond, successfully identifying a new hydrogen-related structure and demonstrating its potential as a long-lived nuclear spin qubit for quantum register applications.

Original authors: Alexander Ungar, Hao Tang, Andrew Stasiuk, Bo Xing, Boning Li, Ju Li, Alexandre Cooper, Paola Cappellaro

Published 2026-04-10

📖 5 min read🧠 Deep dive

CC BY 4.0

Original authors: Alexander Ungar, Hao Tang, Andrew Stasiuk, Bo Xing, Boning Li, Ju Li, Alexandre Cooper, Paola Cappellaro

Original paper licensed under CC BY 4.0 (http://creativecommons.org/licenses/by/4.0/). ✨ This is an AI-generated explanation of the paper below. It is not written or endorsed by the authors. For technical accuracy, refer to the original paper. Read full disclaimer

Imagine a diamond not as a precious gem for jewelry, but as a bustling, microscopic city. Inside this city live tiny, invisible residents called spin defects. Some of these residents are famous celebrities known as Nitrogen-Vacancy (NV) centers. They are like the city's "smart sensors" because they can glow when hit with light and are incredibly sensitive to magnetic fields, making them perfect for building future quantum computers and super-sensitive medical scanners.

However, the city is crowded. Besides the famous NV centers, there are many other "dark" residents—defects we can't see or control yet. These are like neighbors living in the shadows. Some of them are actually very useful; they could act as extra memory chips or processing units for our quantum computers. But because we can't see them clearly, we don't know who they are or how to talk to them.

This paper is about a team of scientists who finally figured out how to introduce themselves to these shadowy neighbors, identify exactly who they are, and start having a conversation with them.

Here is the story of how they did it, broken down into simple steps:

1. The Problem: The "Silent" Neighbors

In the past, scientists tried to study these hidden defects using big, bulky machines (like a giant MRI for atoms). But these machines needed huge magnets and huge groups of atoms to work. It was like trying to hear a single person whisper in a stadium by shouting; you couldn't pick out the specific voice.

The scientists needed a way to listen to just one of these tiny defects at a time, without any magnets, and without needing a crowd.

2. The Solution: The "Echo" and the "Translator"

The team developed a clever two-step strategy using the famous NV center as a middleman.

Step A: The Zero-Field Echo (ZF-DEER)
Imagine you are in a dark room and you want to find a specific person. You shout, and you listen for the echo.

The scientists used the NV center to "shout" (send a microwave pulse) at the hidden defect.
By doing this with zero magnetic field (no magnets involved), they could hear the "echo" of the defect's internal structure.
This gave them a "fingerprint" (called hyperfine components) that told them the defect's unique shape and composition. It was like hearing a specific musical note that only that one defect could play.

Step B: The Triple-Resonance Translator (NEETR)
Now they knew the defect's "voice," but they still couldn't talk to its nuclear spin (the defect's internal memory). The nuclear spin is like a shy person who won't talk to the NV center directly because they are too far apart.

The scientists invented a new protocol called NEETR (Nuclear-Electron-Electron Triple Resonance).
Think of this as a translator. The NV center talks to the defect's electron (the loud, outgoing neighbor). The electron then talks to the nucleus (the shy neighbor).
By using the electron as a bridge, the scientists could finally "hear" the nuclear spin, identify what kind of atom it was, and even send it commands.

3. The Discovery: Meeting Two New Neighbors

Using these tools, the team found two specific defects they had never fully understood before:

Defect X1 (The Hydrogen Mystery): They found a defect made of Hydrogen. This was a surprise! Usually, hydrogen is thought to be "cooked out" of diamonds during manufacturing. Finding a stable hydrogen defect is like finding a rare, exotic plant growing in a desert. They named this new structure MIT1.
Defect X2 (The Nitrogen Confirm): They found a defect made of Nitrogen. This matched a known character they had seen before, confirming their new tools were accurate.

To be absolutely sure, they ran computer simulations (like a digital twin of the diamond) to match the "fingerprints" they found with theoretical models. The match was perfect.

4. The Payoff: Turning Neighbors into Teammates

Once they identified these defects, they didn't just stop at saying "Hello." They started training them.

Initialization: They taught the Hydrogen defect how to start in a specific state (like resetting a computer to "zero").
Control: They could spin the Hydrogen's nuclear spin like a top, turning it into a controllable qubit (a quantum bit).
Memory: The best part? The Hydrogen nuclear spin is incredibly stable. It can hold onto information for 1 millisecond. In the world of quantum physics, where things usually vanish in microseconds, this is an eternity! It's like a sticky note that stays written for a long time.

Why Does This Matter?

Think of a quantum computer as a team of workers.

Before this, we only had a few workers (the NV centers) and we were struggling to find more.
Now, we have discovered a whole new class of workers (the Hydrogen and Nitrogen defects) hiding in the diamond.
Because Hydrogen is rare and distinct, it's easier to tell them apart from the crowd (unlike Nitrogen, which is everywhere and causes confusion).
By using the NEETR translator, we can now build hybrid registers—teams where the NV center does the sensing, and the Hydrogen defect acts as a long-term memory bank.

The Big Picture

This paper is a breakthrough in quantum archaeology. The scientists developed a new set of tools to dig up, identify, and recruit previously unknown quantum particles. They turned "unknowns" into "assets," proving that diamonds are not just beautiful stones, but complex, programmable quantum cities waiting to be fully explored.

In short: They learned how to talk to the silent neighbors in the diamond, found out they were made of Hydrogen, and taught them how to help build the quantum computers of the future.

1. Problem Statement

Diamond spin defects, particularly the Nitrogen-Vacancy (NV) center, are powerful platforms for quantum sensing and networking. While the NV center can be coupled to nearby electron-nuclear defects to form multi-qubit registers, many of these surrounding defects remain uncharacterized.

Limitations of Existing Methods: Conventional Electron Paramagnetic Resonance (EPR) requires large ensembles and strong magnetic fields, lacking the sensitivity to identify single-spin defects. Furthermore, existing single-spin techniques often struggle to resolve hyperfine tensors without precise magnetic field calibration, leading to large uncertainties in defect identification.
The Control Gap: Even when electronic spins of unknown defects are detected, controlling their host nuclear spins is difficult due to the weak direct coupling between the nuclear spin and the NV probe. This prevents the utilization of these nuclear spins as quantum memories.
Goal: The authors aim to develop a self-consistent framework to identify unknown single-spin defects at zero magnetic field, determine their atomic structure, and demonstrate full control (initialization, manipulation, and readout) of their nuclear spins.

2. Methodology

The authors employ a hybrid approach combining advanced quantum control protocols with ab initio calculations:

Zero-Field Double Electron-Electron Resonance (ZF-DEER):
- Instead of sweeping external magnetic fields, the team performs DEER spectroscopy at zero field ( $B_0 \approx 0$ ).
- In this regime, the electron-nuclear spin system eigenstates are Bell states. The transition frequencies depend directly on the principal hyperfine components ( $A_{\parallel}$ and $A_{\perp}$ ) without the complexity of angular misalignment found in high-field measurements.
- This allows for the direct extraction of hyperfine tensor components with high precision, independent of magnetic field calibration errors.
Nuclear-Electron-Electron Triple Resonance (NEETR):
- A novel protocol introduced to detect and control the nuclear spin of a defect that is too far from the NV for direct coupling.
- Mechanism: The protocol leverages the strong electron-electron dipolar coupling between the NV and the target defect (X).
  1. Polarization Transfer: Hartmann-Hahn Cross Polarization (HHCP) transfers polarization from the NV to the defect's electronic spin.
  2. Conditional Drive: An RF pulse is applied to the defect's nuclear spin. If resonant, it flips the nuclear spin, which conditionally flips the defect's electronic spin (via hyperfine interaction).
  3. Readout: The state of the defect's electronic spin is mapped back to the NV via HHCP and read out optically.
- This effectively uses the defect's electron as a "reporter" to detect and control its own nucleus.
Density Functional Theory (DFT):
- Experimental hyperfine components and nuclear species identified via NEETR are compared against extensive DFT calculations of various hydrogen and nitrogen defect structures (including interstitials and vacancies) to assign atomic models.

3. Key Contributions

Development of NEETR: A new protocol enabling the detection and unitary control of nuclear spins in distant defects by mediating through the defect's electronic spin, bypassing the weak NV-nuclear coupling limit.
Zero-Field Characterization Framework: A self-consistent method combining ZF-DEER and NEETR to uniquely identify defect structures without the need for complex magnetic field scanning or calibration.
Discovery of a New Defect (MIT1): The identification and structural assignment of a previously unknown hydrogen-related defect.
Demonstration of Quantum Memory: Full initialization, coherent control, and millisecond-scale coherence measurement of a hydrogen nuclear spin qubit at room temperature.

4. Key Results

Defect Identification:
- Two unknown defects, labeled X1 and X2, were characterized.
- ZF-DEER Results: Extracted hyperfine components:
  - X1: $A_{\parallel} = 39(1)$ MHz, $A_{\perp} = 25(1)$ MHz.
  - X2: $A_{\parallel} = 16(1)$ MHz, $A_{\perp} = 6(1)$ MHz.
- NEETR Results: Identified the nuclear species by measuring the splitting of nuclear resonance frequencies:
  - X1: Splitting matched the gyromagnetic ratio of Hydrogen ( $^1$ H).
  - X2: Splitting matched the gyromagnetic ratio of Nitrogen-15 ( $^{15}$ N).
Structural Assignment (DFT):
- X1 (MIT1): Matched to a $V-CH-V^0$ complex (a divacancy with an interstitial hydrogen atom). This is a newly identified structure, distinct from previously proposed models like WAR2.
- X2 (WAR9): Matched to a known Nitrogen Interstitial ( $N^0_I$ ) defect, consistent with previous literature.
Quantum Control of Hydrogen (X1):
- Initialization: Achieved ~60% polarization of the hydrogen nuclear spin (theoretical max ~70%) using concatenated polarization transfer.
- Coherent Control: Demonstrated Rabi oscillations of the hydrogen nuclear spin with fast Rabi frequencies.
- Coherence Times:
  - Dephasing time ( $T_2^*$ ): $250(60)$ $\mu$ s.
  - Coherence time ( $T_2$ ) via spin-echo: $1.0(3)$ ms.
- This coherence time is approximately 20 times longer than the electronic spin coherence, making it an excellent quantum memory.

5. Significance

Scalability for Quantum Registers: The work establishes a pathway to harness "dark" or unknown defects as auxiliary qubits. Hydrogen defects are particularly valuable because their lower natural abundance compared to nitrogen reduces spectral crowding, allowing for more distinct, addressable qubits within the NV diffraction limit.
Robust Quantum Memory: The demonstration of millisecond-scale coherence for a hydrogen nuclear spin at room temperature validates its potential as a robust quantum memory for error correction and quantum non-demolition (QND) readout schemes.
Generalizability: The NEETR protocol and ZF-DEER characterization framework are not limited to diamond; they can be applied to other wide-bandgap materials (e.g., SiC, GaN, hBN) to accelerate the discovery and utilization of new spin defects for quantum technologies.
Nanoscale Imaging: By enabling control over distant nuclear spins via reporter electrons, this approach paves the way for nanoscale magnetic resonance imaging (MRI) of individual molecules on surfaces.
