High PDMR contrast in single NV centres and related photocurrent properties

This paper elucidates the mechanism of photo-electrical detection of magnetic resonance (PDMR) in single nitrogen-vacancy (NV) centres by demonstrating that interface trap states act as an amplification mechanism for photocurrent generation, enabling PDMR contrasts exceeding 50% through controlled charge cycling without the need for a bias voltage.

Original authors: Michael Petrov, Boo Carmans, Josef Soucek, Akhil Kuriakose, Ottavia Jedrkiewicz, Emilie Bourgeois, Milos Nesladek

Published 2026-03-31

📖 4 min read🧠 Deep dive

CC BY 4.0

Original authors: Michael Petrov, Boo Carmans, Josef Soucek, Akhil Kuriakose, Ottavia Jedrkiewicz, Emilie Bourgeois, Milos Nesladek

Original paper licensed under CC BY 4.0 (http://creativecommons.org/licenses/by/4.0/). ✨ This is an AI-generated explanation of the paper below. It is not written or endorsed by the authors. For technical accuracy, refer to the original paper. Read full disclaimer

Imagine you have a tiny, super-sensitive light switch inside a diamond. This switch is called a Nitrogen-Vacancy (NV) center. Scientists love these switches because they can detect magnetic fields, temperature changes, and even act as the "brain" for future quantum computers.

Usually, to read if this switch is "on" or "off," scientists shine a laser on it and look at the light it bounces back (like a flashlight reflecting off a mirror). This is called ODMR. It works, but the signal is a bit weak, and the "on/off" difference (contrast) is limited to about 30%. It's like trying to hear a whisper in a noisy room.

This paper introduces a new way to listen: PDMR (Photoelectric Detection of Magnetic Resonance). Instead of listening for the light the diamond reflects, they measure the tiny electric current (electricity) flowing through the diamond.

Here is the simple breakdown of what the scientists discovered, using some everyday analogies:

1. The "Hidden Amplifier" (The Real Source of Power)

The scientists expected that the electricity would come directly from the NV switch itself. But they found something surprising.

The Analogy: Imagine the NV center is a small whisperer standing in a large, empty hall. You expect the whisper to travel across the room. But instead, the whisper triggers a giant PA system hidden in the corner of the room. The PA system is what actually makes the sound loud enough to hear.
The Science: The NV center generates a few electrons (tiny charges). These electrons don't go straight to the wire. Instead, they travel to a specific spot on the diamond's surface (near the metal electrode) called a "Source." This Source acts like a faucet. The electrons from the NV center turn the faucet on, allowing a massive flow of electricity (holes) to pour out.
The Result: Because the NV center is just "turning the tap" for a much larger flow, the signal is huge. This is why they achieved a 50% to 90% contrast (a very clear "on/off" signal) compared to the usual 30%.

2. The "Traffic Jam" (The Bridge)

There is a catch. The faucet (Source) only works if the "pipes" aren't clogged.

The Analogy: Imagine the electrons from the NV center are cars driving down a highway to the faucet. But there is a traffic jam (a "Bridge" of trapped electrons) blocking the way. If the traffic jam is full, the cars can't get through, and the faucet stays closed.
The Science: There are "trap levels" (like parking spots) at the interface between the diamond and the metal. When the NV center is working, it fills these traps with electrons. This creates an electric field that opens the faucet at the Source.
The Problem: If you shine light on the "traffic jam" (the Bridge) directly, you clear the cars out, and the faucet shuts off. This creates a "dark spot" in their measurements.

3. The "Second Laser" Trick (Clearing the Jam)

The scientists realized that to get the best signal, they needed to manage this traffic jam perfectly.

The Analogy: Imagine you have a main laser (the main flashlight) that talks to the NV center. But to get the best sound from the PA system, you need a second laser (a helper flashlight) to shine specifically on the traffic jam to keep it clear, ensuring the cars (electrons) keep flowing to the faucet.
The Science: They added a second, "auxiliary" laser. This laser shines on the "Bridge" area to clear out the trapped electrons. By doing this, they could boost the PDMR contrast from a weak 3% up to a massive 20% to 50%.

4. Why This Matters (The Big Picture)

Better Quantum Computers: Reading the state of a quantum bit (qubit) is the hardest part of building a quantum computer. This new method is like upgrading from a tin can telephone to a fiber-optic cable. It's faster, clearer, and easier to miniaturize.
Super Sensors: Because the signal is so strong, these diamond sensors could detect incredibly tiny magnetic fields, like those from a single protein in a living cell, or even the magnetic field of a single atom.

Summary in One Sentence

The scientists discovered that the NV center in a diamond doesn't just generate electricity itself; it acts as a remote control that opens a giant electric faucet at the surface, and by using a second laser to keep the "pipes" clear, they can make the signal incredibly loud and clear, revolutionizing how we read quantum information.

1. Problem Statement

Optically Detected Magnetic Resonance (ODMR) is the standard method for reading out the spin state of Nitrogen-Vacancy (NV) centers in diamond. However, ODMR contrast is fundamentally limited by the quantum transition rates of the NV center, typically capping at ~30% (or ~46% with specific initialization).

Photoelectrically Detected Magnetic Resonance (PDMR) was introduced as an alternative that offers higher spatial resolution (beyond the diffraction limit) and potential for miniaturization. However, PDMR signals have historically suffered from poor reproducibility and low contrast compared to photoluminescence (PL). The photocurrent (PC) is highly sensitive to material defects, surface states, and local electric fields, often resulting in contrasts lower than ODMR. The authors aim to understand the mechanisms limiting PDMR contrast and develop a method to significantly enhance it, potentially exceeding 50%.

2. Methodology

The study utilized a custom-built confocal microscope setup equipped with:

Lasers: A primary 561 nm Nd-YAG laser for NV excitation and an auxiliary 515 nm diode laser.
Samples: Two diamond samples were used:
- Sample M: IIa HPHT diamond with standard Al/Ti metal electrodes.
- Sample G: IIa HPHT diamond with graphite column electrodes fabricated via laser writing.
Measurement Technique: The authors developed a novel "Reset PC scan" technique. In a standard PC map, the laser scans pixel-by-pixel. In the Reset scan, the laser focus returns to the NV center after every pixel measurement. This "resets" the measurement conditions, allowing the researchers to distinguish between current generated directly at the NV center and current generated elsewhere but influenced by the NV center.
Auxiliary Laser: A second laser was introduced to specifically target interface regions (termed "Bridges") to test their role in amplifying the signal.
Modeling: An analytical model was developed based on charge carrier generation rates, trap population dynamics, and current-voltage characteristics.

3. Key Contributions and Findings

A. Identification of "Source" and "Bridge" Mechanisms

The authors discovered that the high photocurrent observed in PDMR does not originate solely from charge carriers generated at the NV center itself. Instead, they identified two distinct phenomena:

The Source: A specific point on the diamond-electrode interface (approx. 50 µm deep in graphite samples) where holes are injected into the diamond. This injection is light-assisted but requires the NV center to be illuminated first.
The Bridge: An intermediate region (likely at the electrode-diamond-air interface) containing electron trap levels.
- Mechanism: The NV center generates electrons under laser illumination. These electrons diffuse to the "Bridge" and populate the trap levels.
- Amplification: The populated traps create a local electric field that lowers the energy barrier for hole injection at the "Source." This amplifies the photocurrent significantly.
- Depletion: Illuminating the "Bridge" with light (or the auxiliary laser) depletes these traps, causing a sharp drop in the photocurrent.

B. The "Subsidiary" Photocurrent

The paper distinguishes between:

Inherent NV PC: Current generated directly at the NV center (typically low contrast).
Subsidiary NV PC: Current generated at the "Source" but controlled by the NV center via the "Bridge."
The authors found that the high PDMR contrast (up to 90% in some cases) is a property of the Subsidiary NV PC, not the inherent NV PC. The NV spin state modulates the electron generation rate, which modulates the trap population at the Bridge, which in turn modulates the hole injection efficiency at the Source.

C. Enhancement of PDMR Contrast

By utilizing the "Reset PC scan" and introducing an auxiliary laser to control the Bridge population, the authors achieved a dramatic increase in PDMR contrast:

Baseline: Without auxiliary control, PDMR contrast was often low (~3%).
Enhanced: By using the auxiliary laser to deplete the Bridge traps (or by positioning the NV center such that the Bridge is naturally illuminated), the contrast was increased from 3% to 20–50%.
Correlation: High contrast is observed only when the NV center is close to a "Bridge" spot. If the Bridge is constantly illuminated (e.g., by the main laser due to proximity), the traps are depleted, and the contrast drops.

D. Analytical Model

The authors developed a mathematical model describing the steady-state photocurrent ( $J_{st}$ ) as a function of:

$G$ : Charge carrier generation rate at the NV center.
$P_B$ : Power of the Bridge illumination (depopulating traps).
$B$ : Bridge population (trap occupancy).

The model suggests that the relationship between photocurrent and generation rate is non-linear. Specifically, the depopulation of traps at the Bridge is a two-photon process ( $b=2$ in their model), and the interaction between the Bridge population and the Source current follows a specific polynomial relationship. This non-linearity explains why PDMR contrast can exceed the theoretical limits of ODMR.

4. Results

Contrast Levels: Achieved PDMR contrasts of 50% and observed up to 90% in specific configurations (SI), significantly surpassing the ~30% limit of ODMR.
Spatial Mapping: Successfully mapped the "Sources" and "Bridges" using the Reset PC scan, revealing that high-contrast NV centers are spatially correlated with specific interface defect sites.
Voltage Independence: The amplification effect works even without an applied bias voltage, driven by the local electric fields at the interface.
Two-Photon Process: Fitting experimental data to the model confirmed that laser-induced trap depletion is a two-photon process.

5. Significance

Quantum Computing & Sensing: This work provides a pathway to read out single NV spins with much higher signal-to-noise ratios (SNR) and contrast than previously possible with ODMR. This is critical for scalable solid-state quantum computing and high-sensitivity quantum sensing.
Mechanism Insight: It resolves the mystery of why PDMR signals are often unstable or low-contrast, identifying interface trap levels as the key variable.
Control Strategy: The demonstration that an auxiliary laser can be used to "tune" the interface states offers a new degree of control for optimizing quantum devices.
Device Miniaturization: Since the mechanism relies on interface effects rather than bulk collection, it supports the development of miniaturized, integrated quantum sensors.

In conclusion, the paper demonstrates that high-contrast PDMR is not an intrinsic property of the NV center alone but a collective phenomenon involving the NV center, interface trap levels (Bridge), and charge injection sites (Source). By actively managing these interface states, PDMR contrast can be engineered to levels far exceeding optical detection limits.
