Entanglement generation of arbitrary squeezed Fock states

This paper proposes an efficient and robust protocol using parametric drives and adiabatic passage within a squeezed reference frame to generate high-fidelity entanglement between a superconducting qubit and a squeezed cavity, enabling the creation of complex non-Gaussian states for fault-tolerant quantum computation and quantum metrology.

Original authors: Qin-Ru Cheng, Ke-Xiong Yan, Yuan Qiu, Yi-Tong Shi, Yan Xia, Ye-Hong Chen

Published 2026-03-31

📖 5 min read🧠 Deep dive

CC BY 4.0

Original authors: Qin-Ru Cheng, Ke-Xiong Yan, Yuan Qiu, Yi-Tong Shi, Yan Xia, Ye-Hong Chen

Original paper licensed under CC BY 4.0 (http://creativecommons.org/licenses/by/4.0/). ✨ This is an AI-generated explanation of the paper below. It is not written or endorsed by the authors. For technical accuracy, refer to the original paper. Read full disclaimer

The Big Picture: Building a "Quantum Bridge"

Imagine you are trying to build a super-advanced computer. To do this, you need two very different types of workers to work together:

The Discrete Worker (The Qubit): Think of this as a light switch. It's either ON (1) or OFF (0). It's great for logic and making decisions, but it's a bit rigid.
The Continuous Worker (The Cavity): Think of this as a vibrating guitar string. It can vibrate at any intensity, holding a vast amount of information in its waves. It's flexible and holds a lot of data, but it's hard to control precisely.

The Problem: Usually, these two workers speak different languages. They struggle to talk to each other, especially when you need them to create a complex, "hybrid" state that combines the best of both worlds.

The Goal of this Paper: The authors propose a new, robust way to force these two workers to dance together perfectly. Specifically, they want to create a "hybrid entanglement" where the light switch (qubit) is linked to a specific, complex vibration pattern (a squeezed state with exactly 3 photons) of the guitar string (cavity).

The Analogy: The "Squeezed" Dance Floor

To make these two different workers dance, the authors use a clever trick involving a parametric drive.

1. The Setup: A Noisy Dance Floor

Imagine the guitar string (cavity) is on a dance floor that is naturally vibrating at a certain speed. The light switch (qubit) is trying to jump in time with it. But, the natural rules of physics (the "Rotating Wave Approximation") say they can only exchange energy one step at a time. They can't do a complex 3-step dance move together.

2. The Magic Trick: The "Squeezed" Reference Frame

The authors suggest changing the perspective. Instead of watching the dance from the side, imagine you put on special 3D glasses (the "squeezed reference frame").

What happens? Through these glasses, the dance floor looks different. The vibrations of the guitar string are "squeezed" (compressed in one direction, stretched in another).
The Result: In this new view, the rules change! The "forbidden" complex moves become allowed. The light switch and the guitar string can now exchange energy in a 3-photon jump (a big leap) instead of just small steps.

3. The Engine: The Parametric Drive

How do we put on these glasses? We apply a parametric drive.

Analogy: Imagine pushing a child on a swing. If you push at the exact right rhythm, the swing goes higher. Here, the scientists are rhythmically squeezing and stretching the "spring" of the cavity. This creates a synthetic environment where the light switch and the cavity can talk to each other much louder and faster than before.

The Process: The "Slow Walk" to Entanglement

Once they have this new, powerful connection, how do they actually create the entangled state? They use a technique called Adiabatic Passage.

The Analogy: Imagine you are walking a tightrope between two cliffs.
- Cliff A: The light switch is ON, and the guitar string is quiet.
- Cliff B: The light switch is OFF, and the guitar string is vibrating wildly (the 3-photon state).
- The Bridge: There is a bridge connecting them, but it's wobbly.
The Method: Instead of jumping across (which might make you fall), the authors slowly tilt the bridge. They gently change the frequency of the cavity, moving it slowly from one side to the other.
The Outcome: Because they move slowly enough, the system "slides" smoothly from Cliff A to Cliff B without falling off. At the end of the walk, the system is in a perfect superposition: The light switch is both ON and OFF, and the guitar string is both quiet and vibrating, all linked together in a single, inseparable quantum state.

Why is this a Big Deal?

It's Robust: The authors show that even if the system is a bit "noisy" (like a real-world lab with imperfect equipment), the dance still works. The "squeezed" view protects the process.
It's Efficient: You don't need extreme, impossible conditions. They found that a "moderate" amount of squeezing (about 5.6 dB, which is achievable with current technology) is enough to make this work.
The Future: This creates a "hybrid" state that is incredibly useful.
- For Computing: It helps build error-correcting codes (like a backup system for your hard drive) that can survive mistakes.
- For Sensing: Because the state is "squeezed," it can detect incredibly weak signals (like a whisper in a hurricane) better than any standard sensor.

Summary

The paper describes a recipe for making a super-precise quantum machine. By using a rhythmic "squeeze" to change the rules of the game, the scientists allow a simple on/off switch to entangle with a complex, vibrating wave. They then gently guide this system into a perfect, linked state that could power the next generation of quantum computers and ultra-sensitive sensors.

1. Problem Statement

The paper addresses the challenge of generating hybrid entanglement between a discrete-variable system (a superconducting qubit) and a continuous-variable system (a cavity mode) in a specific, complex state: a squeezed multi-photon Fock state.

Current Limitations: Existing research focuses on qubit coupling with Gaussian states (coherent/squeezed vacuum) or ordinary Fock states. Generating entanglement involving squeezed Fock states (e.g., $|g, 3\rangle$ $∣ g, 3 ⟩$ combined with squeezing) is difficult because:
- Standard light-matter interactions (Jaynes-Cummings model under Rotating-Wave Approximation) conserve excitation numbers, forbidding high-order multi-photon transitions.
- Achieving the ultra-strong coupling regime required to break this symmetry naturally is experimentally difficult.
- Deterministic generation of non-Gaussian states with high fidelity remains a formidable task.

2. Methodology

The authors propose a protocol utilizing parametric driving and adiabatic passage within a squeezed reference frame.

A. System Model & Transformation

Physical System: A superconducting qubit coupled to a cavity subject to a parametric drive (modulating the cavity frequency).
Hamiltonian: In a frame rotating at half the drive frequency ( $\omega_p/2$ ), the system is described by a Hamiltonian containing counter-rotating terms.
Squeezed Frame Transformation: The authors apply a unitary transformation $U_s(r) = \exp[\frac{r}{2}(a^2 - a^{\dagger 2})]$ $U_{s} (r) = exp [\frac{r}{2} (a^{2} - a^{† 2})]$ to move into a squeezed reference frame.
- The squeezing parameter $r$ is chosen such that $\tanh 2r = \lambda/\delta_c$ .
- Result: The transformed Hamiltonian becomes an anisotropic Rabi model ( $H_{aR}$ $H_{a R}$ ). Crucially, this transformation:
  1. Exponentially enhances the effective coupling strengths ( $\lambda_1, \lambda_2 \propto e^r$ ).
  2. Introduces robust counter-rotating terms that enable high-order transitions.
  3. Maps the cavity vacuum $|0\rangle$ in the new frame to a squeezed vacuum in the lab frame.

B. Analytical Derivation

High-Order Time-Averaging: Using a high-order time-averaging method, the authors derive an effective Hamiltonian for the three-photon process.
Resonance Condition: They derive the precise condition for three-photon resonance ( $\omega_q \approx 3\omega_c$ $ω_{q} \approx 3 ω_{c}$ ) and calculate the effective Rabi frequency ( $\Omega_{eff}$ $Ω_{e f f}$ ) for the transition between $|e, 0\rangle$ $∣ e, 0 ⟩$ and $|g, 3\rangle$ $∣ g, 3 ⟩$ in the squeezed frame.
- $\Omega_{eff} \propto \lambda_1 \lambda_2^2 / \omega_c^2$ .
- The coupling is exponentially enhanced by the squeezing parameter $r$ .

C. Adiabatic Protocol

Strategy: To deterministically generate entanglement, the system is initialized in the state $|e, 0\rangle$ (in the squeezed frame) at a large detuning.
Sweep: The cavity frequency $\omega_c(t)$ is slowly swept across the three-photon resonance point.
Mechanism: According to the Landau-Zener theorem, if the sweep rate $v$ satisfies the adiabatic condition ( $\eta = |\Omega_{eff}|^2/v \gg 1$ ), the system follows the instantaneous eigenstate, evolving into a maximally entangled Bell-like state:
$|\Psi_{res}\rangle_{SF} = \frac{1}{\sqrt{2}}(|e, 0\rangle - |g, 3\rangle)$
Lab Frame Mapping: Transforming back to the laboratory frame yields the target hybrid entangled state:
$|\Psi\rangle_{Lab} = \frac{1}{\sqrt{2}} (|e\rangle \otimes S(r)|0\rangle - |g\rangle \otimes S(r)|3\rangle)$

3. Key Contributions

Theoretical Framework: Successfully mapped the parametrically driven Jaynes-Cummings model to an anisotropic Rabi model in a squeezed frame, enabling the analytical derivation of three-photon resonance conditions without requiring the ultra-strong coupling regime.
Parameter Optimization: Demonstrated that a moderate squeezing level ( $r \approx 0.65$ , approx. 5.6 dB) is sufficient to achieve high-fidelity state preparation. This is a significant practical advantage, as it avoids the extreme experimental challenges associated with ultra-high squeezing.
Robustness Analysis: Showed that the protocol is robust against environmental noise (cavity decay $\kappa$ and qubit relaxation $\gamma$ ), maintaining high fidelity and concurrence under realistic circuit QED parameters.
Experimental Feasibility: Proposed a concrete implementation scheme using superconducting circuit QED (Transmon qubit, LC resonator, and SQUID-based parametric drive), mapping physical circuit components to the theoretical model parameters.

4. Results

Analytical vs. Numerical Agreement: The analytical derivation of the energy level splitting ( $\Delta E$ ) and effective Rabi frequency matches numerical diagonalization results with less than 3% error for coupling strengths $g < 0.047$ .
State Preparation Fidelity:
- Numerical simulations show the population of the target squeezed three-photon state reaches 99.63% under ideal conditions.
- The fidelity peaks near $r=0.65$ , confirming that moderate squeezing is optimal.
Adiabatic Evolution: Simulations confirm smooth population transfer from $|e, 0\rangle$ to $|g, 3\rangle$ with the concurrence reaching its maximum at the end of the sweep.
Noise Tolerance: Under realistic dissipation rates ( $\kappa = 0.009\omega_q$ , $\gamma = 0.0001\omega_q$ ), the protocol achieves a fidelity of 0.77 and concurrence of 0.71, proving experimental viability.
Wigner Function: The Wigner phase-space distributions confirm the transition from a squeezed vacuum to a squeezed three-photon Fock state.

5. Significance

Fault-Tolerant Quantum Computing: The ability to generate hybrid entanglement between qubits and non-Gaussian states (like squeezed Fock states) is a critical resource for bosonic quantum error correction (e.g., cat codes, GKP codes), which are essential for fault-tolerant quantum computing.
Quantum Metrology: Squeezed Fock states combine the phase sensitivity of squeezed states with the non-Gaussianity of Fock states, offering potential for measurements that surpass the standard quantum limit.
Experimental Accessibility: By demonstrating that high-fidelity generation is possible with moderate squeezing and standard circuit QED parameters, this work provides a practical and feasible pathway for experimentalists to synthesize complex non-Gaussian entangled states, bridging the gap between theoretical proposals and laboratory realization.
