From London to Morse via Binnig, Quate, and Gerber

Imagine a world where you can see and touch individual atoms, the tiny building blocks that make up everything around us. For decades, scientists have used a special kind of microscope called an atomic force microscope to do just that. Instead of using light, which is too big to see atoms, this instrument uses a needle so sharp it ends in a single atom. As this needle hovers over a surface, it feels the invisible forces pulling or pushing between itself and the atoms below. These forces range from the very weak, gentle tugs that hold dust together, to the incredibly strong bonds that hold molecules together. The big question for researchers has always been: is this needle just a passive observer, quietly recording what is there, or is it an active participant that changes what it sees?

A team of researchers from the University of Nottingham and other institutions has spent twenty years answering this question. They have taken a journey through the different types of forces that exist at the atomic scale, starting with the weakest and moving to the strongest. Their work shows that the needle is never just a passive observer; it is always interacting with the surface, sometimes gently and sometimes so strongly that it moves atoms around. By understanding exactly how the needle behaves, they have learned how to build tiny structures atom by atom, and they are now teaching computers to help them do it even better.

The story begins with the weakest forces, the kind that hold nanoparticles together in a thin layer on a surface. The researchers watched a film of tiny gold particles, each only about two nanometers wide, sitting on a silicon surface. When they scanned this surface with their atomic needle, something surprising happened. The particles, which were initially scattered in a messy, maze-like pattern, began to rearrange themselves into larger, smoother clumps. This didn't happen because of heat or natural aging; it happened because the needle itself was pushing and pulling the particles as it scanned back and forth. The needle acted like a tiny, local energy source, nudging the particles until they found a more stable arrangement. This process, called coarsening, showed that even the gentlest touch from the microscope could reshape a surface, proving that the tool itself was driving the change.

Moving up the scale of strength, the team looked at how two individual soccer-ball-shaped molecules, known as fullerenes, interact with each other. They managed to pick up one of these molecules and stick it to the very tip of their needle. Then, they brought this tip close to another fullerene sitting on the surface. By measuring the force between them, they mapped out exactly how the two molecules attracted and repelled each other. They found that the way the molecules were oriented relative to each other mattered a great deal. Even though the overall force was attractive, the specific shape of the molecules meant that the repulsive forces between their atoms were what actually determined how they settled together. This detailed mapping showed that the interaction was far more complex than a simple attraction; it was a delicate balance of forces that depended entirely on how the molecules were turned.

The researchers then turned their attention to a common type of chemical connection called a hydrogen bond, which is crucial for holding many biological molecules together. In the past, scientists had claimed to see these bonds directly in microscope images as bright lines connecting molecules. However, the Nottingham team found that these bright lines were often illusions. When they scanned a surface where molecules were held together by hydrogen bonds, they saw bright lines exactly where the bonds should be. But when they analyzed the data carefully, they realized these lines were not the bonds themselves. Instead, they were caused by the flexible tip of the microscope bending slightly as it moved over the surface, creating an image that looked like a bond even when none was there. This discovery was a major correction to the field, showing that what looks like a chemical bond in a microscope image might just be an artifact of the tool's own movement.

To go beyond these illusions, the team moved to the strongest forces of all: covalent bonds, which are the rigid links that hold atoms together in a solid structure. They focused on a silicon surface where pairs of atoms, called dimers, were locked together but could flip back and forth like a switch. By pressing the needle down with just the right amount of force, they were able to flip these atomic switches, changing the orientation of the atoms on command. However, they found that they could not flip just one atom in isolation; the action always affected its neighbors. This taught them that the local environment is critical; the atoms are so tightly connected that changing one inevitably changes the others. This level of control is essential for building future atomic-scale devices, but it requires a deep understanding of how the entire group of atoms reacts to the probe.

The ultimate goal of this work is to build structures from the bottom up, placing atoms one by one to create new materials. The team demonstrated this by picking up individual copper atoms from a surface and depositing them in a specific pattern. They learned that they could not just push atoms around sideways; sometimes they had to lift them off the surface and drop them in a new spot. This vertical manipulation allowed them to build clusters of atoms that could not be made by sliding them around. For example, they managed to create a tight, triangular cluster of three copper atoms, a shape that was impossible to form using only sideways movements. This ability to move atoms up and down, as well as side to side, opened up new ways to construct complex, three-dimensional shapes at the atomic level.

Throughout all these experiments, the researchers realized that the shape of their needle was the most important variable. A perfect, single-atom tip is an ideal that rarely exists in reality. Their microscope tips were often messy, with multiple atoms sticking out, which changed how they interacted with the surface. Sometimes this messiness helped them see things they couldn't see with a perfect tip, but other times it created confusing images. To solve this, they began using artificial intelligence to help. They trained computer programs to recognize the shape of the tip and to decide the best way to move it. These programs could learn from thousands of attempts to find the perfect sequence of movements to pick up and place atoms, effectively automating the process of building with matter.

The work of this team highlights a fundamental truth about looking at the atomic world: the tool you use is part of the experiment. You cannot simply observe the atoms; you are always interacting with them. Whether it is gently nudging a particle, flipping a switch, or building a new structure, the microscope is an active participant. By understanding the limits and capabilities of their tools, and by using smart computers to guide them, these scientists are moving closer to a future where we can design and build materials atom by atom, creating things that have never existed before.
