Effect of Annealing on Maze Domains in Topological Insulator - Magnetic Multilayer Heterostructures

This study demonstrates that in-situ annealing at approximately 200°C enhances domain ordering and enables field-induced skyrmion nucleation in Bi $_2$ Se $_3$ -based topological insulator-magnetic multilayers while preserving the magnetic robustness of the interface up to 350°C despite structural deterioration of the topological insulator film.

Original authors: Benjamin A. Brereton, Soumyarup Hait, Christy J. Kinane, Francesco Maccherozzi, Ahmet Yagmur, Satoshi Sasaki, Thomas A. Moore, Sean Langridge, Christopher H. Marrows

Published 2026-10-22

📖 4 min read☕ Coffee break read

CC BY 4.0

Original authors: Benjamin A. Brereton, Soumyarup Hait, Christy J. Kinane, Francesco Maccherozzi, Ahmet Yagmur, Satoshi Sasaki, Thomas A. Moore, Sean Langridge, Christopher H. Marrows

Original paper licensed under CC BY 4.0 (http://creativecommons.org/licenses/by/4.0/). ✨ This is an AI-generated explanation of the paper below. It is not written or endorsed by the authors. For technical accuracy, refer to the original paper. Read full disclaimer

In the quest to build faster, more efficient computers, scientists are looking to a class of materials known as topological insulators. Imagine a material that acts as a perfect insulator on the inside, blocking the flow of electricity, yet conducts electricity effortlessly along its surface. This unique behavior arises from the way electrons move on the surface, where they become locked to their direction of travel, creating a stream of particles that are highly organized and resistant to scattering. When these materials are paired with magnetic layers, they can generate powerful forces that twist and turn magnetic patterns with very little electrical current. This capability is crucial for the next generation of data storage, where information is written not by moving heavy electrical charges, but by manipulating tiny magnetic textures. However, these promising materials face a practical hurdle: they are often fragile. The specific topological insulator used in many experiments, made of bismuth and selenium, tends to break down or lose its special properties when heated, which is a problem because building electronic devices often requires high temperatures to stabilize the magnetic layers on top of them.

A team of researchers at the University of Leeds and collaborating institutions set out to solve this puzzle by testing how much heat these delicate structures could actually withstand. They created a sandwich-like stack of materials, starting with a layer of the bismuth-selenium topological insulator, followed by a thin buffer layer, and then a repeating pattern of platinum, cobalt, and ruthenium metals. This magnetic stack was designed to host "maze domains," which are complex, winding patterns of magnetism that can serve as the foundation for storing data. The scientists wanted to know if they could bake the sample to improve the magnetic patterns without destroying the topological insulator underneath. To find the answer, they placed the sample in a vacuum chamber and slowly heated it in steps, stopping every 50 degrees Celsius to measure what was happening inside the layers. They used two powerful tools to look at the sample: one that fired neutrons to see the magnetic strength deep inside the material, and another that used X-rays to map the magnetic patterns on the surface.

The results revealed a clear boundary between what the device could survive and what it could not. When the researchers heated the sample to 350 degrees Celsius, the topological insulator layer suffered severe damage, losing its crystalline structure and breaking down. However, the magnetic layers on top remained surprisingly strong and intact, showing no signs of the magnetic "death" that occurs when atoms from the bottom layer diffuse upward and ruin the magnetism. This confirmed that the thin buffer layer between the insulator and the magnet acted as an effective shield. More importantly, the team discovered a "sweet spot" for heating. When they stopped the process at a moderate temperature of roughly 200 degrees Celsius, the magnetic layers improved significantly without harming the insulator. At this temperature, the chaotic maze of magnetic domains became more ordered and uniform, and something remarkable happened: tiny, stable magnetic whirlpools known as skyrmions began to form. These skyrmions are highly prized in computing because they are small, stable, and easy to move, making them ideal candidates for future data bits.

The study demonstrates that it is possible to use standard heating techniques to optimize the magnetic properties of these advanced devices without sacrificing the underlying topological material. By finding the right temperature, the researchers were able to sharpen the interface between the magnetic layers and encourage the formation of these useful magnetic textures. This finding is a practical step forward, suggesting that engineers can incorporate these heat-treatment steps into the manufacturing process for next-generation spintronic devices. The work confirms that while the topological insulator itself has limits, the magnetic system built upon it is robust enough to be tuned and improved, opening the door to more reliable and efficient ways of manipulating magnetic data using the unique properties of topological surfaces.

Technical Summary: Effect of Annealing on Maze Domains in Topological Insulator - Magnetic Multilayer Heterostructures

Problem Statement
The integration of topological insulators (TIs), specifically Bi₂Se₃, with chiral magnetic multilayers (MMLs) offers a pathway to enhance spin-orbit torque (SOT) driven manipulation of spin textures, such as magnetic skyrmions. However, a significant barrier to the practical application of these heterostructures is the thermal instability of Bi₂Se₃ films. While post-growth annealing is a standard procedure for optimizing magnetic multilayers—often to enhance perpendicular magnetic anisotropy (PMA) or the interfacial Dzyaloshinskii-Moriya interaction (iDMI)—the Bi₂Se₃ layer is susceptible to structural deterioration, surface oxidation, and selenium (Se) loss at temperatures exceeding ~200 °C. This creates a conflict: the thermal processing required to optimize the magnetic multilayer risks degrading the topological insulator, while the low resistance of the metal films makes the device prone to Joule heating during operation. The critical question addressed is whether an annealing step can improve the magnetic domain ordering of the multilayer without compromising the structural integrity of the TI or inducing magnetic deadness at the interface.

Methodology
The study investigates a heterostructure stack consisting of a Bi₂Se₃(20 nm) epilayer grown via molecular beam epitaxy (MBE) on sapphire, capped with a Ta(1.5 nm) buffer and a repeating magnetic multilayer [Pt(0.8)/CoB(0.6)/Ru(0.5)]×6/Ru(0.5). The samples were subjected to in-situ annealing in a rough vacuum (~10⁻³ mbar) at the ISIS Neutron and Muon Source. The annealing process involved incremental heating in 50 °C steps up to 350 °C, with measurements taken after each cycle.

A multi-modal characterization approach was employed:

Polarised Neutron Reflectometry (PNR): Used as a depth-resolved magnetic probe to monitor changes in the magnetic scattering length density (SLD) profiles and detect potential magnetic deadness or interdiffusion at the TI/MML interface.
X-ray Reflectometry (XRR) and Diffraction (XRD): Utilized to assess structural changes, crystallinity, and the integrity of the Bi₂Se₃ layer.
SQUID Vibrating Sample Magnetometry (VSM): Measured macroscopic magnetic properties, including saturation magnetization ( $M_s$ ) and hysteresis loops.
X-ray Photoemission Electron Microscopy (X-PEEM) with XMCD: Performed at the Diamond Light Source on a sample annealed to 200 °C to visualize magnetic domain structures and skyrmion nucleation under applied fields.

Key Results

Structural Stability: XRD and Atomic Force Microscopy (AFM) confirmed that while the magnetic multilayer remains robust, the Bi₂Se₃ epilayer suffers significant structural breakdown at 350 °C, characterized by a drastic reduction in XRD peak intensity and the formation of mixed Bi-Se phases. However, at an intermediate temperature of ~200 °C, the crystallinity of the Bi₂Se₃ is largely preserved.
Magnetic Robustness: PNR measurements revealed that the magnetic multilayer remains magnetically robust up to 350 °C. Crucially, no magnetic deadness was observed at the bottom ferromagnetic layer, indicating that the Ta buffer layer effectively suppresses Se diffusion from the TI. The saturation magnetization ( $M_s$ ) increased by approximately 20–31% after annealing, attributed to an improved Co/Pt interface and an increase in interfacial anisotropy ( $K_i$ ), which compensated for the expected reduction in effective anisotropy due to higher $M_s$ .
Domain Ordering and Skyrmion Nucleation: X-PEEM imaging of the sample annealed at 200 °C showed a significant improvement in magnetic domain ordering. The average domain width decreased by ~40% (from 600 nm to 340 nm), and the distribution became sharper. Most notably, this annealed sample exhibited the nucleation of skyrmion-like features under an applied out-of-plane magnetic field, a phenomenon not observed in the as-grown control sample. These skyrmions demonstrated relative stability against field permutations.

Significance and Claims
The paper establishes that a thermal annealing step at ~200 °C can be successfully implemented in TI-MML heterostructures to improve magnetic domain ordering and facilitate skyrmion nucleation without destroying the topological insulator layer. The authors claim this is the first demonstration, via PNR, that refractory metal buffer layers (specifically Ta) effectively act as diffusion barriers against Se, preserving the magnetic functionality of the multilayer even at elevated temperatures.

The study concludes that the operational temperature limit for such devices is dictated by the structural breakdown of the Bi₂Se₃ layer rather than the degradation of the magnetic multilayer. By transferring established annealing protocols from conventional Pt/Co-based systems to TI-MML heterostructures, the work demonstrates a viable route to optimizing these materials for next-generation spintronic devices that rely on SOT-driven spin texture manipulation. The observation of skyrmions in this specific heterostructure configuration provides a foundation for future experiments involving TSS-driven skyrmion dynamics.
