Light Transmission through Multilayer Metal Gratings with Periodic Slit Array Structures

This paper utilizes the rigorous coupled-wave analysis method to demonstrate that a multilayer periodic silver grating with slit arrays significantly enhances extraordinary optical transmission through surface plasmon resonance coupling at the metal–dielectric interfaces and between adjacent layers.

Original authors: Li Qun, Fang Cheng, Chen Zhiming

Published 2026-09-15

📖 4 min read☕ Coffee break read

CC BY 4.0

Original authors: Li Qun, Fang Cheng, Chen Zhiming

Original paper licensed under CC BY 4.0 (https://creativecommons.org/licenses/by/4.0/). ✨ This is an AI-generated explanation of the paper below. It is not written or endorsed by the authors. For technical accuracy, refer to the original paper. Read full disclaimer

Light behaves in ways that often defy our everyday intuition, particularly when it encounters metal. Normally, a solid sheet of metal acts as a perfect mirror, reflecting light and blocking it from passing through. However, if you drill tiny holes in that metal sheet, something surprising happens: light can pass through with much greater efficiency than simple geometry would predict. This phenomenon, known as extraordinary optical transmission, occurs because the light interacts with ripples of electrons on the metal's surface. These ripples, called surface plasmons, act like a bridge, allowing energy to tunnel through the tiny openings. While scientists have long studied this effect in single sheets of metal, a new study explores what happens when you stack multiple metal layers on top of one another, creating a more complex, three-dimensional structure. Understanding how light moves through these stacked layers could help engineers design better filters and sensors for future optical devices.

Researchers at the East China University of Technology set out to investigate how the number of metal layers affects this light transmission. They designed a computer model of a structure made of silver, a metal known for its ability to support these electron ripples. Imagine a stack of silver films, each pierced with a row of narrow slits. In their design, the total thickness of the metal remained constant at 1000 nanometers, but the number of layers varied. They tested structures with one, two, three, four, and five layers, adjusting the spacing between the layers to find the configuration that allowed the most light to pass through. To analyze this, they used a sophisticated calculation method called rigorous coupled-wave analysis, which tracks how electromagnetic waves interact with the periodic pattern of the slits and the metal layers.

When they looked at a single layer of silver with a thickness of 1000 nanometers, the light passed through most efficiently at two specific wavelengths: 1340 nanometers and 2590 nanometers. At these points, the light resonated with the metal, creating strong peaks in transmission. However, when the researchers split that same amount of metal into two separate layers, the behavior changed dramatically. The sharp peak at 1340 nanometers disappeared, replaced by a broader band of transmission between 1500 and 1550 nanometers. The peak at 2590 nanometers vanished entirely from the range they were studying. As they continued to increase the number of layers to three, four, and five, the transmission spectrum became even more complex. The single peak that existed in the one-layer structure began to split into multiple distinct peaks. For instance, the three-layer structure showed four separate transmission peaks, while the five-layer structure displayed sharp peaks at 1400 and 1990 nanometers.

The researchers found that as the number of layers increased, the light did not simply get blocked; instead, the transmission peaks shifted toward longer wavelengths and multiplied. This splitting occurs because the light is no longer interacting with just one surface. In a multi-layer stack, the electron ripples on the top of one layer can talk to the ripples on the bottom of the layer above it. This interaction creates new, hybrid pathways for the light to travel. The simulations showed that at the wavelengths where transmission was highest, the magnetic field of the light became intensely concentrated within the slits and in the gaps between the metal layers. This concentration is driven by the coupling of surface plasmons across the different metal-dielectric interfaces. Essentially, the layers work together to trap and guide the light through the structure more effectively than a single thick sheet could.

One of the most significant findings was that the broad transmission peak seen in the single-layer structure at 2590 nanometers gradually weakened and eventually disappeared as more layers were added. This suggests that the specific waveguide resonance that allowed light to pass through the single thick layer was disrupted by the introduction of the gaps between the thinner layers. Instead, the system relied on the coupling between the layers to transmit light. The study confirms that extraordinary optical transmission in these slit arrays is not just about the size of the holes, but about the precise resonance of surface plasmons at the boundaries between the metal and the air. By controlling the number of layers and the spacing between them, it is possible to tune exactly which wavelengths of light are allowed through. This level of control offers a new way to manipulate light in devices that require precise filtering or sensing, moving beyond what is possible with simple, single-layer metal films.

Technical Summary: Light Transmission through Multilayer Metal Gratings with Periodic Slit Array Structures

Problem Statement
While the phenomenon of Extraordinary Optical Transmission (EOT) through metallic thin films with periodic apertures is well-established, a systematic understanding of how EOT evolves in purely metallic, planar, multilayer slit gratings remains incomplete. Previous investigations have largely focused on single or double-layer structures, or multilayer systems with non-uniform geometries (e.g., tapered slits, corrugated films) or material heterogeneity (e.g., Au/Al combinations). These variations introduce confounding factors such as total thickness changes, geometric tapering, and material differences, making it difficult to isolate the specific effects of increasing the number of functional metal layers. There is a lack of literature characterizing the transmission peak positions, intensities, and field distributions in equal-thickness multilayer silver gratings where the total metal thickness is held constant while the layer count varies from one to five.

Methodology
The authors employed the Rigorous Coupled-Wave Analysis (RCWA) method to simulate the electromagnetic transmission characteristics of two-dimensional periodic silver (Ag) film grating structures.

Structure: The model consists of silver layers separated by air gaps, surrounded by air. The total metal thickness ( $H$ ) was fixed at 1000 nm. For $n$ layers, each layer had an equal thickness of $H/n$ (ranging from 1000 nm for a single layer down to 200 nm for five layers). The grating period ( $D$ ) was fixed at 1000 nm, and the slit width ( $a$ ) was 100 nm.
Optimization: The interlayer spacing ( $G$ ) was not fixed a priori but was optimized for each layer count ( $n=2$ to $5$) to maximize transmission intensity. The optimized spacings were found to be 150 nm, 100 nm, 40 nm, and 20 nm, respectively.
Simulation Parameters: Simulations covered a wavelength range of 1000–3000 nm under Transverse Magnetic (TM) polarization. The silver dielectric constant was modeled using the Drude model ( $\varepsilon_\infty=3.7$ , $\hbar\omega_p=9.1$ eV, $\hbar\gamma=0.048$ eV). Convergence was verified using 21 retained Fourier diffraction orders.
Analysis: The study analyzed transmission spectra and calculated steady-state magnetic field ( $H_z$ ) distributions to elucidate physical mechanisms.

Key Results

Transmission Spectra Evolution:
- Single-Layer Reference: A 1000 nm single-layer grating exhibited transmission peaks at 1340 nm and 2590 nm, with a weak peak at 1020 nm.
- Peak Splitting and Redshift: As the number of layers increased, the primary peak at 1340 nm split into multiple sub-peaks that gradually redshifted. For instance, the three-layer grating showed peaks at 1080 nm, 1300 nm, 1510 nm, and 2850 nm.
- Disappearance of Long-Wavelength Peak: The broad peak observed at 2590 nm in the single-layer structure diminished in intensity and eventually disappeared from the calculated spectral range as the layer count increased.
- EOT Confirmation: At all transmission peaks, the transmittance significantly exceeded the geometric open area ratio (10%), confirming the occurrence of EOT.
Field Distribution and Mechanism:
- Field Localization: Steady-state magnetic field analysis revealed that at transmission peaks, the field is strongly localized within the slits and between adjacent metal layers.
- Coupling Resonance: The enhanced transmission is attributed to the coupling resonance of surface plasmons (SPPs) at the metal–dielectric interfaces.
- Mode Hybridization: In multilayer structures, the introduction of additional interfaces creates new hybridized plasmonic modes. For example, in the three-layer structure, resonant modes formed between the first and third layers, as well as between adjacent layers (1-2 and 2-3).
- Symmetry: The resonant modes exhibited vertical and horizontal symmetry, consistent with surface plasmon coupling resonance.

Significance and Claims
The paper claims to provide a controlled investigation into the evolution of EOT behavior by isolating the variable of layer count while maintaining constant total thickness and geometry. The authors conclude that:

The EOT behavior in metal grating slit arrays fundamentally originates from the coupling resonance of surface plasmons at the metal–dielectric interface.
Multilayer configurations modify the effective dielectric environment, leading to the splitting of transmission peaks and the generation of hybridized resonance modes due to interlayer evanescent coupling.
The disappearance of the long-wavelength Fabry–Pérot-like waveguide resonance (seen at 2590 nm in single layers) is caused by the disruption of this resonance by reduced individual layer thickness and interlayer coupling.

These findings offer a more detailed understanding of EOT mechanisms in purely metallic multilayer structures, which the authors suggest could inform the design of subwavelength optical devices such as plasmonic filters, sensors, and modulators. The study does not propose specific experimental fabrication protocols or new applications beyond these general design implications.
