Role of Wadsley Defects and Cation Disorder to Enhance MoNb12O33 Diffusion

This study demonstrates that introducing Wadsley defects and transition metal disorder in MoNb12O33 anodes significantly enhances lithium diffusion kinetics and high-rate capacity by activating fast diffusion paths at lower lithiation levels, as confirmed through combined experimental characterization and machine-learning molecular dynamics simulations.

Original authors: CJ Sturgill, Manish Kumar, Nima Karimitari, Iva Milisavljevic, Coby S. Collins, Aaron Hegler, Hsin-Yun Joy Chao, Santosh Kiran Balijepalli, Scott Misture, Christopher Sutton, Morgan Stefik

Published 2026-07-22

📖 3 min read☕ Coffee break read

CC BY 4.0

Original authors: CJ Sturgill, Manish Kumar, Nima Karimitari, Iva Milisavljevic, Coby S. Collins, Aaron Hegler, Hsin-Yun Joy Chao, Santosh Kiran Balijepalli, Scott Misture, Christopher Sutton, Morgan Stefik

Original paper licensed under CC BY 4.0 (http://creativecommons.org/licenses/by/4.0/). ✨ This is an AI-generated explanation of the paper below. It is not written or endorsed by the authors. For technical accuracy, refer to the original paper. Read full disclaimer

Imagine the inside of a battery as a bustling city where tiny, charged messengers called lithium ions are constantly rushing to deliver energy. For a battery to be powerful and charge quickly, these ions need to zip through the city's streets without getting stuck in traffic jams. Scientists have been looking for the perfect "city layout" for these ions, and they've found a promising candidate in a family of materials called Wadsley-Roth niobates. Think of these materials as a unique architectural design made of stacked blocks of atoms. These blocks have built-in tunnels and windows that act as highways for the ions. However, just like a real city, the efficiency of these highways depends on how perfectly the buildings are arranged. If the buildings are too orderly, the roads might be narrow or crowded. But what if the buildings were slightly jumbled or had some "construction zones" (defects)? Could that actually make the traffic flow faster? This is the big question researchers are asking: can a little bit of messiness in the atomic structure actually make a battery perform better?

In this study, the researchers decided to test this idea using a specific material called MoNb12O33. They created two versions of this material: one that was heated to a lower temperature (800°C) to keep it full of "defects" or atomic jumbles, and another heated to a higher temperature (900°C) to make it more orderly and perfect. They called the messy version MNO-800 and the tidy version MNO-900. When they tested these materials in battery cells, the messy MNO-800 was the clear winner. It could hold more energy and, more importantly, it could charge and discharge much faster. At a very high speed (10C), the messy version could still deliver 200 mAh/g of capacity, while the tidy version struggled to keep up.

To understand why the messy version was faster, the scientists looked at the atomic structure like detectives. They found that the lower-temperature MNO-800 had two main types of "imperfections": the blocks of atoms were of different sizes (some bigger, some smaller), and the metal atoms inside were mixed up in places they usually don't go. In contrast, the MNO-900 had uniform blocks and a neat arrangement of atoms. By measuring how fast lithium ions moved through the material, they discovered that the messy MNO-800 allowed ions to diffuse about three times faster than the tidy version.

The researchers then used powerful computer simulations to figure out exactly how these imperfections helped. They built digital models of the perfect structure, the mixed-up atoms, and the different block sizes. Their simulations suggested that in the perfect, tidy structure, the lithium ions had to wait until the battery was almost full before they could find the fastest "express lanes" to move through. However, in the messy models, these fast lanes were open and ready to use much earlier in the charging process. It's as if the messy construction created shortcuts that were available from the very start, whereas the perfect city forced the ions to take a long, slow route until the very end. The study concludes that these specific types of defects—variable block sizes and mixed-up atoms—work together to unlock faster movement for the ions, offering a new way to design better, faster-charging batteries.

Technical Summary: Role of Wadsley Defects and Cation Disorder to Enhance MoNb12O33 Diffusion

Problem Statement
Wadsley-Roth (WR) niobates are promising high-rate anode materials due to their rapid ionic diffusion, good electronic conductivity, and structural stability during cycling. While defect engineering via limited annealing has been shown to enhance transport in WR materials, the specific mechanistic contributions of different defect types remain unclear. Specifically, WR compounds often contain a mixture of Wadsley defects (variable block sizes/intergrowths) and transition metal cation disorder. Previous studies have suggested that increased block size and cation disorder can accelerate lithium diffusion, but these factors are often coupled with other structural changes (e.g., oxygen vacancies, interface variations), making it difficult to isolate their individual effects on transport properties. This study addresses the need to parse the separate roles of Wadsley defects and cation disorder in enhancing lithium diffusion within the WR compound MoNb12O33 (MNO).

Methodology
The authors synthesized MoNb12O33 using a sol-gel strategy followed by calcination at two distinct temperatures: 800°C (MNO-800) and 900°C (MNO-900). These conditions were selected to produce a defect-rich state (MNO-800) and a more ordered state (MNO-900), respectively, while maintaining the same nominal stoichiometry.

Structural Characterization: The materials were analyzed using powder X-ray diffraction (XRD) with Rietveld refinement, X-ray absorption spectroscopy (XANES and EXAFS) at Nb and Mo K-edges, and High-Angle Annular Dark-Field Scanning Transmission Electron Microscopy (HAADF-STEM). STEM was used to directly observe block sizes and interface types, while Radial Distribution Function (RDF) analysis was applied to STEM images to quantify local atomic spacings.
Electrochemical Testing: Lithium half-cells were assembled and subjected to galvanostatic cycling at various C-rates (0.1C to 20C). Intermittent Current Interruption (ICI) was employed to deconvolute overpotentials and quantify solid-state diffusion coefficients. Small-Angle X-ray Scattering (SAXS) was used to determine specific surface areas for diffusivity calculations.
Computational Modeling: To decouple the effects of defects, the authors employed Density Functional Theory (DFT), Machine-Learned Interatomic Potentials (MLIP), and Molecular Dynamics (MD) simulations. Three model types were constructed:
1. Pristine: A defect-free T[3×4] block structure.
2. Cation Disordered: T[3×4] structures with varied Mo/Nb placement (including Special Quasirandom Structures).
3. Variable Block Size: Models with T[3×5] blocks and mixed T[3×4]-T[3×5] phases to simulate Wadsley defects.
  Nudged Elastic Band (NEB) calculations determined activation barriers, while Cluster Expansion (CE) combined with Monte Carlo (MC) simulations predicted the sequence of lithium site occupation.

Key Results

Structural Differences: MNO-800 exhibited significantly higher microstrain and a highly defective local environment compared to MNO-900. STEM revealed MNO-800 contained a variety of block sizes (ranging from [2×5] to [5×5]) and mixed interface types (T-type and E-type), whereas MNO-900 was predominantly T[3×4]. EXAFS analysis indicated that the local Mo environment in MNO-800 was highly defective with a higher average coordination number and bond length variations, unlike the predominantly tetrahedral coordination in MNO-900.
Electrochemical Performance: MNO-800 demonstrated superior electrochemical performance. At 0.1C, it achieved a reversible capacity of 307 mAh/g (4.66% higher than MNO-900). At high rates, MNO-800 retained 200 mAh/g at 10C and 151 mAh/g at 20C, significantly outperforming MNO-900. Long-term cycling at 20C showed ~74% capacity retention after 10,000 cycles.
Diffusion Kinetics: ICI analysis identified solid-state diffusion as the dominant rate-limiting process. MNO-800 exhibited a capacity-weighted average diffusivity ( $D_{av}$ ) approximately 3 times higher than MNO-900 ( $1.80 \times 10^{-17}$ vs. $5.72 \times 10^{-18}$ m²/s). The diffusivity advantage was most pronounced during the early stages of lithiation.
Computational Insights: Simulations revealed that both cation disorder and variable block sizes (Wadsley defects) facilitate faster lithium diffusion by altering the sequence of site occupation. In the pristine model, fast-diffusing window sites (Wh and Wv) were only populated at high lithium concentrations ( $x \ge 11.5$ ). In contrast, both disordered and variable-block models populated these fast sites at significantly lower lithium concentrations ( $x \ge 3.5$ to $x \ge 6$ ). While cation disorder placed at the center of blocks slowed diffusion in specific "near" windows, the overall effect of disorder and block size variation was to activate fast diffusion pathways earlier in the lithiation process.

Significance and Claims
The paper claims to provide a mechanistic understanding of how specific defects enhance performance in WR niobates. The authors conclude that both Wadsley defects (variable block sizes) and transition metal cation disorder contribute to enhanced performance in MNO-800. The primary mechanism identified is not necessarily a change in the intrinsic diffusion barrier of a single hop, but rather a shift in the thermodynamic sequence of lithium site occupation. These defects enable the population of fast-diffusing window sites at lower extents of lithiation, thereby accelerating overall transport rates. The study validates that defect engineering, specifically through controlled annealing to retain Wadsley defects and cation disorder, is a viable strategy to accelerate diffusivity in intercalation materials, offering a pathway to develop high-power battery anodes with improved rate capability and stability.
