Structural and Optical Characteristics of beta-Ga2O3 Implanted with Rare Earth Ions

This study investigates the structural and optical properties of rare-earth-ion-implanted beta-Ga2O3, revealing that implantation-induced disorder and defect evolution are largely independent of the specific ion species, while demonstrating that RE3+ ions are excited via the host conduction band and maintain efficient emission even in the presence of significant lattice damage.

Original authors: Renata Ratajczak, Joanna Matulewicz, Slawomir Prucnal, Maciej O. Liedke, Cyprian Mieszczynski, Przemyslaw Jozwik, Ulrich Kentsch, Rene Heller, Eric Hirschmann, Andreas Wagner, Wojciech Wozniak, Freder

Published 2026-03-12

📖 5 min read🧠 Deep dive

CC BY 4.0

Original authors: Renata Ratajczak, Joanna Matulewicz, Slawomir Prucnal, Maciej O. Liedke, Cyprian Mieszczynski, Przemyslaw Jozwik, Ulrich Kentsch, Rene Heller, Eric Hirschmann, Andreas Wagner, Wojciech Wozniak, Frederico Garrido, Elzbieta Guziewicz

Original paper licensed under CC BY 4.0 (http://creativecommons.org/licenses/by/4.0/). ✨ This is an AI-generated explanation of the paper below. It is not written or endorsed by the authors. For technical accuracy, refer to the original paper. Read full disclaimer

The Big Picture: Fixing a Crystal City

Imagine $\beta$ -Ga $_2$ O $_3$ (Beta-Gallium Oxide) as a super-strong, ultra-modern city made of crystal. This city is famous for being tough against heat and radiation, making it perfect for high-tech jobs like space satellites or nuclear power plants. However, this city has a problem: it's naturally a bit "naked" (it conducts electricity in a way that's hard to control) and it only glows in invisible ultraviolet light.

The scientists wanted to turn this city into a neon-lit wonderland that glows in visible colors (like red, green, or blue) or infrared light. To do this, they decided to drop in some special "guests" called Rare Earth ions (like Dysprosium, Erbium, and Ytterbium). These guests are like tiny lightbulbs that can glow in specific, beautiful colors.

The Method: The "Punch and Heal" Strategy

To get these lightbulb guests inside the crystal city, the scientists used a technique called Ion Implantation.

The Punch: They fired high-speed ions at the crystal. Think of this like throwing a bunch of bowling balls into a house of cards. It knocks the cards (the atoms) out of place, creating a mess of disorder and damage.
The Heal: To fix the mess, they heated the crystal up quickly (a process called Annealing). This is like sending in a team of construction workers to put the cards back in order.

The Discovery 1: The "Guests" Don't Matter as Much as You Think

The scientists wondered: Does it matter if we throw in heavy guests (like Ytterbium) or lighter ones (like Erbium)? Do they break the city differently?

The Result: Surprisingly, no.
Whether they threw in Dysprosium, Erbium, or Ytterbium, the damage looked exactly the same. The "bowling balls" broke the crystal structure in an identical way, turning a neat layer of the city into a chaotic, amorphous pile.

The Analogy: Imagine dropping a heavy rock, a brick, and a bag of sand into a pile of sand. Regardless of what you drop, the hole you make looks the same. The type of "guest" didn't change how the crystal got damaged.

The Discovery 2: The "Construction Workers" Can't Fix Everything

After the "healing" heat treatment, the scientists checked if the city was perfect again.

The Result: It wasn't perfect. While the big mess was cleaned up, the construction workers didn't remove every single broken piece. Instead, they pushed the small broken pieces together to form larger clusters (like gathering scattered bricks into a few big piles).
The Analogy: Imagine a room full of scattered Lego bricks. The heat treatment didn't pick up every single brick. Instead, it pushed the loose bricks into a few big, messy piles. The room looks cleaner from a distance, but if you look closely, the damage is still there, just rearranged.

The Discovery 3: How the Lightbulbs Turn On

This is the most exciting part. The scientists wanted to know: How do these Rare Earth guests get the energy to glow?

There were two theories:

Theory A: The guest gets hit directly by a specific type of energy, jumps to a high shelf (the 5d shell), and then slides down to glow.
Theory B: The guest waits for the whole city to get excited first.

The Result: The scientists found that Theory B is correct.

The Mechanism: When they shine a light on the crystal, the entire city (the host material) gets excited first. The energy travels through the "conduction band" (like a highway) of the crystal. The Rare Earth guests hop off this highway, relax a bit, and then glow.
The Analogy: Imagine a concert.
- Theory A suggests the singer (the guest) gets a direct microphone boost.
- Theory B (which is what happened) suggests the whole crowd (the crystal) starts cheering and clapping. The energy from the crowd travels through the venue, and the singer catches that energy to perform.
- Crucial Finding: It doesn't matter which singer (Dysprosium, Erbium, or Ytterbium) is on stage; they all use the same "crowd energy" highway to get their performance started.

The Discovery 4: Too Many Guests is Bad (Concentration Quenching)

The scientists tested what happens if they put too many lightbulbs in the crystal.

The Result: If you put too many guests in a small room, they start bumping into each other and tripping over their own feet. The light starts to dim. This is called Concentration Quenching.
The Silver Lining: Even with a lot of damage and disorder in the crystal, the lightbulbs (especially Ytterbium) still managed to glow very brightly. This means the material is very robust and can handle a lot of abuse while still working.

Why Does This Matter?

This paper is a roadmap for engineers. It tells us:

Don't worry about the specific guest: You can use different Rare Earth ions, and the crystal will react the same way.
Don't expect perfection: The crystal will never be 100% perfect after this process, but it doesn't need to be to work well.
The light switch is simple: We know exactly how to turn these lights on (by exciting the whole crystal first), which helps us design better lasers, LEDs, and sensors for space and nuclear applications.

In short: The scientists figured out how to break a super-tough crystal, fix it just enough, and fill it with colorful lightbulbs that all use the same power source, proving that even a "damaged" crystal can shine bright.

1. Problem Statement

β-Ga2O3 is a promising wide-bandgap semiconductor for deep-UV photonics and power electronics. However, its optical properties are often dominated by unintentional defects (like oxygen vacancies) and cross-contaminations (Si, Sn), making it difficult to engineer specific emission wavelengths.

Challenge 1: Incorporating Rare Earth (RE) ions (Dy, Er, Yb) to tune emission into the visible and near-infrared regions is difficult due to low solubility limits, which often lead to segregation or secondary phase formation.
Challenge 2: Ion implantation, a precise method for dopant incorporation, inevitably creates significant lattice disorder and radiation-induced phase transitions (from $\beta$ -phase to $\gamma$ -phase and eventually amorphous structures).
Challenge 3: The excitation mechanism of RE ions in $\beta$ -Ga2O3 remains debated. Previous studies suggested excitation via the host conduction band followed by relaxation to 4f states, while others proposed involvement of 5d energy levels.
Challenge 4: It is unclear whether the structural recovery and defect evolution after annealing depend on the specific mass or type of the implanted RE ion, and how these structural changes affect the optical efficiency of the RE ions.

2. Methodology

The study utilized a multi-technique approach to correlate structural evolution with optical performance:

Sample Preparation:
- Substrate: (-201)-oriented n-type $\beta$ -Ga2O3 single crystals.
- Implantation: Ions of Dysprosium (Dy), Erbium (Er), and Ytterbium (Yb) were implanted at 150 keV with fluences of $1\times10^{13}$ , $1\times10^{14}$ , and $1\times10^{15}$ ions/cm².
- Annealing: Rapid Thermal Annealing (RTA) at 800°C for 10 minutes in an Oxygen atmosphere to induce structural recovery and optical activation.
Structural Characterization:
- RBS/c (Rutherford Backscattering Spectrometry in channeling mode): Used to analyze lattice disorder, damage accumulation, and phase transitions ( $\beta \to \gamma \to$ amorphous).
- Positron Annihilation Spectroscopy (PAS):
  - DB-VEPAS (Doppler Broadening): To profile defect concentrations and types (vacancies vs. clusters).
  - VEPALS (Variable Energy Positron Lifetime): To determine the size and nature of vacancy clusters and voids.
Optical Characterization:
- Photoluminescence (PL): Measured emission spectra from UV to Near-Infrared (NIR) at room temperature.
- Photoluminescence Excitation (PLE): Scanned excitation wavelengths (200–600 nm) while monitoring specific emission peaks to determine the excitation pathways of RE ions and intrinsic defects.

3. Key Contributions

Systematic Comparison: First comprehensive comparison of Dy, Er, and Yb implantation in $\beta$ -Ga2O3, demonstrating that structural damage and recovery are largely independent of the specific RE species.
Defect Evolution Mechanism: Clarified that post-annealing does not simply "heal" the lattice but drives a rearrangement of defects, transforming small vacancy clusters into larger complexes.
Excitation Mechanism Resolution: Provided strong evidence against the 5d-level excitation model for these RE ions in $\beta$ -Ga2O3, proposing a unified conduction-band-mediated excitation mechanism.
Concentration Quenching: Identified the onset of concentration quenching for Yb³⁺ and demonstrated that high luminescence efficiency can be maintained even in highly disordered lattices.

4. Key Results

Structural Evolution

Phase Transitions: Implantation induces a phase transition from the stable $\beta$ -phase to the $\gamma$ -phase at ~0.25 displacements per atom (dpa, fluence $\approx 1\times10^{14}$ ions/cm²). At higher fluences ( $1\times10^{15}$ ions/cm²), the $\gamma$ -phase partially transforms into an amorphous layer.
Ion Independence: The damage accumulation and phase transition thresholds were identical for Dy, Er, and Yb, indicating the process is driven by lattice strain rather than ion mass.
Post-Annealing Recovery:
- Annealing at 800°C restores the $\beta$ -phase but does not fully eliminate defects.
- Defect Rearrangement: Positron lifetime analysis revealed that annealing causes small vacancy clusters ( $\tau_1$ ) to shrink while larger vacancy agglomerates ( $\tau_2$ ) grow. This suggests a coalescence of defects into larger complexes rather than their total annihilation.
- The defect microstructure (size and distribution) was found to be similar across all three RE ions.

Optical Properties

Intrinsic Defects: Unimplanted samples showed strong UV-visible emission (365 nm, 401 nm, 462 nm) attributed to oxygen vacancies ( $V_O$ ) interacting with self-trapped holes (STH).
RE Emission:
- Dy³⁺: Sharp lines at ~480, 492, and 585 nm (visible).
- Er³⁺: Emission at ~1540 nm (NIR).
- Yb³⁺: Emission at ~980 nm (NIR).
- Despite significant lattice disorder (especially at high fluences), RE ions retained high luminescence efficiency.
Excitation Mechanism (PLE):
- PLE spectra for all RE ions (Dy, Er, Yb) showed a dominant excitation peak at ~240 nm (5.1 eV), matching the $\beta$ -Ga2O3 bandgap.
- A secondary peak at ~275 nm corresponded to oxygen vacancy excitation.
- Conclusion: The excitation mechanism involves direct excitation of electrons into the host conduction band, followed by non-radiative relaxation to the RE 4f excited states, and finally radiative decay. This contradicts models suggesting direct 5d-level involvement, as the excitation profile is identical for all RE ions despite their different 5d energy levels.
Concentration Quenching: For Yb³⁺, emission efficiency peaked at $1\times10^{15}$ ions/cm² and decreased at higher fluences due to concentration quenching.

5. Significance

This work provides critical guidelines for the development of $\beta$ -Ga2O3:RE systems for optoelectronic applications:

Process Optimization: It confirms that annealing conditions (800°C, O₂) are robust across different RE dopants, simplifying the fabrication process for multi-doped devices.
Defect Engineering: The finding that annealing rearranges defects rather than removing them suggests that future strategies should focus on managing defect clustering to minimize non-radiative recombination centers.
Excitation Pathway: Establishing a unified conduction-band excitation mechanism simplifies the theoretical modeling of RE-doped $\beta$ -Ga2O3, removing the need to calculate complex 5d-level interactions for each specific ion.
Robustness: The demonstration that RE luminescence remains efficient even in highly disordered (partially amorphous) lattices indicates that $\beta$ -Ga2O3 is a highly resilient host for rare-earth doping, suitable for radiation-hardened applications in space and nuclear environments.
