Dual-Gradient Plasmonic qBIC Metasurface for Time-Resolved In Situ Optimization of Molecular Vibrational Sensing in Water

This paper presents a dual-gradient plasmonic qBIC metasurface that enables real-time, in situ optimization of molecular vibrational sensing in water by spatially encoding spectral and radiative parameters to overcome water absorption and identify optimal sensing conditions for monitoring biological dynamics.

Original authors: Tao Jiang, Michael Hirler, Lina Rohrer, Martin Barkey, Dmytro Gryb, Leonardo de S. Menezes, Silvia Holler, Stefan A. Maier, Yohan Lee, Alexander A. Antonov, Andreas Tittl

Published 2026-09-01

📖 5 min read🧠 Deep dive

CC BY 4.0

Original authors: Tao Jiang, Michael Hirler, Lina Rohrer, Martin Barkey, Dmytro Gryb, Leonardo de S. Menezes, Silvia Holler, Stefan A. Maier, Yohan Lee, Alexander A. Antonov, Andreas Tittl

Original paper licensed under CC BY 4.0 (http://creativecommons.org/licenses/by/4.0/). ✨ This is an AI-generated explanation of the paper below. It is not written or endorsed by the authors. For technical accuracy, refer to the original paper. Read full disclaimer

To understand the molecules that make up life, scientists often turn to light. Specifically, they use a type of invisible light called mid-infrared radiation. Every molecule has a unique way of vibrating, much like a guitar string has a specific note it plays. When mid-infrared light hits a molecule, the molecule absorbs the light at the exact frequency that matches its vibration. By measuring which frequencies are absorbed, researchers can identify what the molecule is and how it is behaving. This method is powerful because it requires no labels or dyes; it simply listens to the natural language of the atoms. However, there is a major obstacle when trying to study living things. Most biological processes happen in water, and water is a voracious absorber of mid-infrared light. It swallows the signal so completely that the faint whispers of the molecules researchers want to study are often drowned out. For years, this has made it difficult to watch biological processes in real time within their natural, watery environment.

A team of researchers has now developed a new way to hear those whispers clearly, even through the noise of water. They created a tiny, flat chip covered in a pattern of microscopic gold shapes. This chip acts as a highly sensitive trap for light, designed to amplify the faint signals from molecules sitting on its surface. The innovation lies in how the chip is built. Instead of making a single type of trap, the researchers created a surface where the shape and size of the traps change gradually across the chip. This allows them to test thousands of different settings simultaneously on a single device. By doing this, they were able to find the perfect setting to detect the vibrations of lipids, the building blocks of cell membranes, while they were floating in water. This work demonstrates a new path for observing biological dynamics in real time, offering a way to study life as it happens without the interference that has long plagued infrared sensing.

The core of this new technology is a surface patterned with tiny, diamond-shaped gold resonators. Imagine a field of microscopic diamonds, each only a few hundred nanometers wide. When light hits these shapes, it gets caught in a specific state where it bounces around inside the structure for a long time before escaping. This trapped light creates a very strong electric field right at the surface of the gold. If a molecule lands on the surface, it interacts with this intense field, and its vibrational signal becomes much stronger. The researchers found that using sharp, diamond-shaped corners was significantly better than using the rounded shapes used in previous designs. The sharp points concentrate the light even more, creating "hot spots" where the interaction with molecules is maximized. This design choice alone boosted the strength of the signal by about thirty percent, making it possible to see signals that would otherwise be too weak to detect.

To solve the problem of finding the right setting for different molecules, the team introduced a dual-gradient design. On one side of the chip, the size of the diamond shapes changes gradually. On the other side, the angle of the diamonds changes. These two changes act like two different dials. The size dial shifts the frequency of the light the chip traps, allowing it to match the specific vibration of different molecules. The angle dial controls how strongly the chip talks to the outside world, adjusting how sensitive it is to the molecules. By varying both across a single chip that is roughly the size of a postage stamp, the researchers created a map of thousands of possible configurations. Instead of building many different chips and hoping one of them works, they built one chip that contains every possible variation. This means they can instantly find the exact combination of size and angle that produces the strongest signal for a specific molecule.

The researchers tested this system by watching lipid vesicles, which are tiny bubbles made of cell membrane material, as they moved through water and settled onto the chip. They wanted to see if they could detect the vibration of the carbonyl group, a specific part of the lipid molecule, even though water absorbs light at that same frequency. As the vesicles arrived and stuck to the surface, the chip recorded the changes in light reflection in real time. The data showed that the signal grew stronger as more lipids covered the surface. Crucially, the researchers could look at the entire map of the chip and see exactly where the signal was strongest. They found a specific region on the chip where the size and angle of the diamonds were perfectly matched to the lipid vibration. In this optimal spot, the system successfully isolated the lipid signal from the overwhelming background noise of the water.

This approach marks a shift from trying to guess the right design to simply letting the chip find the answer for itself. The researchers were able to track the entire process of the lipids arriving, sticking, and forming a layer, all while identifying the best conditions for sensing. They confirmed through computer simulations that the sharp corners of the diamonds and the specific angles of the traps were responsible for the improved performance. The results show that it is possible to monitor molecular dynamics in water with high precision, provided the sensing surface is tuned correctly. By integrating the search for the optimal setting directly into the device, this method removes the need for trial and error. It offers a compact, single-chip solution that can adapt to different molecules and changing conditions, opening the door to studying complex biological processes in their natural, watery state with a clarity that was previously out of reach.

Technical Summary: Dual-Gradient Plasmonic qBIC Metasurface for Time-Resolved In Situ Optimization of Molecular Vibrational Sensing in Water

Problem Statement
Mid-infrared (mid-IR) spectroscopy offers label-free molecular detection but faces significant challenges when applied to aqueous biological environments. While Surface-Enhanced Infrared Absorption (SEIRA) using resonant metasurfaces can enhance sensitivity, real-time sensing in water is hindered by two primary factors: (1) strong water absorption in the mid-IR region, which damps photonic resonances and obscures weak analyte signals; and (2) the difficulty of matching the spectral position and coupling strength of a metasurface resonance to specific molecular vibrational modes. Conventional approaches often require multiple discrete arrays, iterative fabrication, or angle-dependent measurements to find the optimal sensing condition, increasing device footprint and complexity. Furthermore, existing dielectric quasi-bound states in the continuum (qBICs) suffer from large mode volumes that extend into the surrounding medium, making them highly susceptible to water-induced damping.

Methodology
The authors present a single-chip solution: a dual-gradient plasmonic qBIC metasurface fabricated on a calcium fluoride (CaF2) substrate. The design incorporates two independent spatial gradients across a 1000 μm × 700 μm footprint:

Scaling Factor Gradient ( $S$ ): Varies the lateral dimensions of the resonators to tune the spectral position of the qBIC across a broad wavenumber range.
Asymmetry Parameter Gradient ( $\theta$ ): Varies the opening angle of the resonators to control the radiative decay rate and coupling strength to the far field.

Key design innovations include:

Diamond-Shaped Resonators: Replacing conventional elliptical nanorods with diamond-shaped gold nanorods to leverage the "lightning-rod effect" at sharp corners. This geometry enhances near-field localization and increases the quality factor (Q-factor) by approximately 32.2% compared to elliptical counterparts.
Dual-Gradient Encoding: The metasurface maps a full parameter space of resonator configurations on a single chip, eliminating the need for multiple fabricated arrays.
Experimental Setup: The device was integrated into a custom microfluidic system for in situ monitoring of 1-palmitoyl-2-oleoyl-sn-glycero-3-phosphocholine (POPC) lipid vesicles in water. A 5 nm SiO2 layer was deposited to promote vesicle adsorption. Hyperspectral reflectance imaging was performed from the substrate side to minimize the optical path length through water.
Data Processing: Analyte adsorption was modeled using an effective-medium approximation with an analyte coverage ratio (CR). Experimental absorbance was calculated by comparing reflectance spectra with and without analyte, followed by baseline correction to isolate vibrational signatures from refractive index changes.

Key Contributions

Design Optimization: Demonstrated that diamond-shaped plasmonic resonators provide superior near-field enhancement and Q-factors compared to elliptical designs, specifically beneficial for sensing in lossy aqueous environments.
Single-Chip Optimization: Established a method to spatially encode both spectral position and radiative coupling strength, allowing for the simultaneous identification of the optimal sensing condition (spectral overlap and critical coupling) without prior knowledge of the target resonance.
Real-Time Kinetics: Developed a framework for monitoring molecular adsorption dynamics (vesicle rupture and bilayer formation) in real time while continuously mapping the sensing performance across the parameter space.

Results

Numerical Modeling: Simulations indicated that the optimal asymmetry parameter for maximizing absorbance in water is approximately $\theta = 12.5^\circ$ , representing a trade-off between radiative coupling and intrinsic losses. The model showed that the optimal condition remains relatively stable across varying analyte coverage ratios.
Experimental Verification: Reflectance measurements confirmed that the scaling factor $S$ effectively tunes the resonance position, while the asymmetry parameter $\theta$ controls the resonance amplitude and linewidth. The dual-gradient design successfully mapped the spectral and coupling variations across the chip.
In Situ Sensing: The system successfully detected the carbonyl (C=O) stretching vibration of POPC lipid vesicles at ~1735 cm⁻¹ despite strong water absorption.
- Real-time monitoring revealed an initial rapid increase in integrated absorbance (vesicle adsorption and rupture) followed by gradual saturation (bilayer formation).
- Spatial mapping of the integrated absorbance identified a distinct region of maximum response centered around $S = 0.87$ and $\theta = 20^\circ$ .
- The experimentally observed optimal asymmetry ( $\theta = 20^\circ$ ) was slightly higher than the numerical prediction ( $12.5^\circ$ ), attributed to intrinsic losses in the aqueous environment and fabrication deviations, yet the stability of the optimal region over time aligned with theoretical expectations.

Significance
The paper claims to demonstrate the first instance of globally optimizing a qBIC sensing condition during in situ molecular vibrational sensing in water on a single chip. By integrating adsorption-kinetics monitoring, vibrational fingerprint detection, and on-chip optimization, this approach provides a compact strategy for investigating biological dynamics under physiologically relevant aqueous conditions. The authors position this technology as a versatile framework that moves mid-IR metaphotonic sensing from proof-of-concept demonstrations toward practical analytical applications, such as point-of-care diagnostics and live-cell metabolism studies, where the optimal resonance condition is often unknown a priori.
