Symmetry-protected triplet Weyl complexes

This paper systematically identifies the symmetry conditions allowing for triplet Weyl complexes with mixed chiral charges in magnetic space groups, predicting a novel $\{1,2,3\}$ configuration and experimentally realizing a $\{1,1,2\}$ state in the chiral carbon allotrope DZQH-C $_{36}$ .

Original authors: Yun-Yun Bai, Ke-Xin Pang, Yan Gao, Weikang Wu, Shengyuan A. Yang

Published 2026-09-07

📖 4 min read☕ Coffee break read

CC BY 4.0

Original authors: Yun-Yun Bai, Ke-Xin Pang, Yan Gao, Weikang Wu, Shengyuan A. Yang

Original paper licensed under CC BY 4.0 (http://creativecommons.org/licenses/by/4.0/). ✨ This is an AI-generated explanation of the paper below. It is not written or endorsed by the authors. For technical accuracy, refer to the original paper. Read full disclaimer

In the hidden architecture of solid materials, electrons do not simply flow like water in a pipe; they move through a landscape shaped by the crystal's internal symmetry. Sometimes, under specific conditions, these electrons behave as if they are massless particles, creating points in the material's energy structure called Weyl nodes. For decades, a fundamental rule of physics, known as the Nielsen-Ninomiya theorem, dictated that these nodes could only appear in pairs, like positive and negative charges that must balance each other out to keep the material electrically neutral. This rule seemed to lock the behavior of electrons into a rigid pattern: one node here, its opposite there, and nothing in between. However, scientists have long suspected that the complex symmetries found in real crystals might allow for exceptions, where multiple nodes could cluster together in ways that bypass the old rules, creating new and exotic states of matter.

A team of researchers has now mapped out exactly how these exceptions can occur, revealing that nature allows for a specific, previously unknown arrangement of three nodes working together. By systematically checking every possible type of crystal symmetry, including those found in magnetic materials, the team discovered that while the old rule of pairs is usually strict, crystals can stabilize a "triplet" configuration. In this setup, three distinct points where electron paths cross can coexist, provided their combined charges cancel out to zero. The researchers found that only two specific combinations of these charges are possible: a group with charges of one, one, and two, and a more exotic group with charges of one, two, and three. Crucially, they proved that other theoretical combinations, such as groups with charges of one, three, and four, cannot exist in stable crystals, effectively closing the door on those possibilities.

The study went beyond theory to show exactly where these nodes live within the crystal's structure. For the group with charges of one, one, and two, the team identified that the three nodes can arrange themselves in a triangle, a pattern seen in earlier work, but they also discovered a new, straight-line arrangement where all three sit on a single axis. Even more significantly, they confirmed the existence of the one-two-three group, a configuration that had never been observed before. This new group requires a very specific type of magnetic crystal symmetry, and the researchers demonstrated its existence by building a precise mathematical model of such a crystal. In this model, the three nodes align perfectly along a vertical axis, with the middle node carrying a charge of two and the outer nodes carrying charges of one and three, all balancing each other out.

To prove that these strange states are not just mathematical curiosities but real physical possibilities, the researchers turned to a newly proposed form of carbon. They identified a specific carbon structure, made of twisted ribbons of atoms, that naturally hosts the straight-line, one-one-two triplet. Using powerful computer simulations based on the laws of quantum mechanics, they showed that this carbon material is stable and that its electrons indeed form the predicted three-node pattern. In this material, the nodes are arranged in a line, and this specific geometry forces the electrons on the surface of the crystal to trace a unique path. Instead of the usual loops or straight lines, the surface electrons form a distinct "S" shape, a fingerprint that could be detected by shining light on the material and measuring how the electrons respond.

This work provides a complete guide for finding these rare topological states in the real world. By listing the specific symmetries required to create them, the researchers have given experimentalists a clear map of which materials to look for. The discovery of the one-two-three triplet and the identification of the carbon allotrope as a host for the one-one-two triplet suggest that the universe of electronic materials is richer than previously thought. These findings do not just fill a gap in a textbook; they open a new chapter in the search for materials with unique electronic properties, where the interplay of symmetry and charge creates behaviors that were once thought impossible. The path forward is now clear: look for crystals with the right symmetry, and you may find these hidden triplets waiting to be explored.

Technical Summary: Symmetry-Protected Triplet Weyl Complexes

Problem Statement
The Nielsen-Ninomiya no-go theorem dictates that Weyl nodes in a lattice must appear in pairs of opposite chirality to preserve global charge neutrality. While previous research has identified configurations where crystalline symmetries allow for multi-Weyl nodes or "Weyl complexes" with mixed chiral charges, the scope of these configurations remains largely unexplored. Specifically, the minimal such configuration—a Triplet Weyl Complex (TWC) comprising exactly three Weyl nodes—has only been reported in limited examples with {1, 1, 2} chiral charge magnitudes, primarily within phononic spectra. Fundamental questions regarding the full range of possible chiral charge combinations, the distribution of nodes within the Brillouin zone (BZ), and the specific symmetry conditions required to stabilize them remain unanswered. Furthermore, a fermionic (electronic) realization of TWCs has not yet been established.

Methodology
The authors conducted a systematic symmetry analysis across all 1651 magnetic space groups (MSGs), considering both spinless and spinful systems (with and without spin-orbit coupling). The analysis was guided by the following constraints:

Charge Neutrality: The sum of chiral charges must be zero ( $C_1 + C_2 + C_3 = 0$ ).
Stability Limits: The magnitude of stabilized chiral charges is limited to $|C| \in \{1, 2, 3, 4\}$ .
Symmetry Constraints: The MSG must allow the coexistence of specific charge magnitudes and ensure exactly three nodes exist (avoiding symmetry-enforced duplication). This involves analyzing the size of the "Star" of the k-points and ensuring point groups do not contain improper rotations that would flip chiral charges.

Based on these conditions, the authors screened the MSGs to identify permissible TWC configurations. To validate the findings, they:

Constructed a tight-binding lattice model on a hexagonal lattice constrained by MSG 169.113 (P61) to demonstrate the existence of a novel TWC type.
Performed first-principles calculations on a chiral carbon allotrope, DZQH-C36, to identify a material realization of a collinear TWC.
Analyzed surface spectra and Berry curvature distributions to characterize the topological features.

Key Contributions and Results

Classification of Permissible TWCs:
The study establishes that only two combinations of chiral charge magnitudes are permitted for TWCs in crystals:
- {1, 1, 2}: Realizable in 166 spinless and 70 spinful MSGs.
- {1, 2, 3}: A previously unknown configuration realizable in 10 MSGs (5 Type-I and 5 Type-III) for both spinless and spinful cases.
- Excluded Configurations: The study proves that {1, 3, 4} and {2, 2, 4} TWCs cannot be stabilized in crystals under the derived symmetry conditions.
Discovery of New Node Distributions:
- Collinear {1, 1, 2}: While previous reports identified triangular configurations, this work identifies a new "collinear" configuration where the three nodes lie on the same high-symmetry path (specifically the $\Gamma$ -A path) in the BZ.
- Collinear {1, 2, 3}: The authors demonstrate that the novel {1, 2, 3} configuration requires the three nodes to be collinearly distributed on a sixfold screw axis ( $k_z$ -axis).
Lattice Model Demonstration:
Using a 12-band spinless tight-binding model constrained by MSG 169.113, the authors explicitly demonstrated the {1, 2, 3}-TWC. The model features three crossing points ( $W_1, W_2, W_3$ ) along the $k_z$ axis with chiral charges of $\pm 1$ , $\pm 2$ , and $\pm 3$ , respectively. Effective $k \cdot p$ models confirmed $W_3$ as a cubic Weyl node ( $|C|=3$ ), $W_2$ as a quadratic node ( $|C|=2$ ), and $W_1$ as an elementary node ( $|C|=1$ ).
Electronic Realization in DZQH-C36:
The authors identified the chiral carbon allotrope DZQH-C36 as a material host for the collinear {1, 1, 2}-TWC.
- Structure: The material consists of sp2-hybridized distorted zigzag nanoribbons and sp3-hybridized quadrilateral helical nanoribbons, forming a hexagonal lattice with space groups P61 or P65.
- Electronic Properties: First-principles calculations confirm DZQH-C36 is a stable semimetal. The band structure reveals three Weyl nodes on the $\Gamma$ -A path: a quadratic node ( $W_2$ ) at the $\Gamma$ point and two elementary nodes ( $W_1, W_1'$ ) on the path.
- Topological Signatures: Numerical tracing of the Wannier charge center confirmed the {1, 1, 2} charge configuration. The collinear arrangement of these nodes leads to a characteristic "S"-shaped Fermi arc pattern on the side surfaces, distinct from the arcs associated with triangular configurations.

Significance
The paper claims to settle fundamental questions regarding the existence and symmetry requirements of Triplet Weyl Complexes. By mapping the permissible configurations across all magnetic space groups, the work reveals a new class of topological states featuring mixed chiral charges ({1, 2, 3}) and a new geometric arrangement (collinear) for the known {1, 1, 2} type. Crucially, the identification of DZQH-C36 provides the first electronic (fermionic) realization of a TWC semimetal, moving beyond previous phononic examples. The findings offer a theoretical framework and specific material guidance for exploring novel topological phenomena, such as competing localization effects in transport and characteristic surface Fermi arc patterns, in concrete material systems.
