Assessing network RTK degradation under ionospheric disturbances using the I95 index
This study demonstrates that the I95 index, derived from double-differenced ionospheric residuals, serves as an effective empirical indicator for predicting Network RTK performance degradation under low-latitude ionospheric disturbances, establishing specific threshold values that define four distinct performance regimes and revealing a significantly stronger degradation effect in 2024 compared to 2019.
Original paper licensed under CC BY 4.0 (https://creativecommons.org/licenses/by/4.0/). This is an AI-generated explanation of the paper below. It is not written or endorsed by the authors. For technical accuracy, refer to the original paper. Read full disclaimer
Imagine you are trying to navigate a city using a high-tech map app that promises to guide you with centimeter-level precision. This isn't just a regular GPS; it's a super-powered version called Network RTK, which uses a team of stationary "referee" towers scattered across the region to correct your phone's signal in real-time. Think of these towers as a choir of experts singing a perfect note, helping your device tune out the static and find its exact spot. However, there is a mischievous weather system that loves to mess with this choir: the ionosphere. This is a layer of charged particles high above the Earth that acts like a wobbly, invisible lens. When the sun gets active, this lens can ripple and distort, scrambling the signals between the towers and your phone. If the distortion gets too wild, your "perfect" map app might suddenly think you are in the next neighborhood over, or worse, lose its ability to lock onto your location entirely. Scientists have long known this happens, but they needed a better way to predict when the lens gets too wobbly to trust the map.
This paper acts like a detective story, investigating how a specific "stress test" number, called the I95 index, can warn us when the ionosphere is about to ruin our high-precision navigation. The researchers used data from a network of 13 GPS stations in Hong Kong, a region known for having a particularly jittery ionosphere. They looked at two different years: 2019, which was a quiet year for solar activity, and 2024, a year when the sun was much more active and the ionosphere was throwing more tantrums. By comparing the "stress level" (the I95 index) against how well the network actually performed, they discovered a clear pattern: as the I95 number goes up, the navigation system gets significantly worse, but not just a little bit worse—it gets chaotic.
The team found that the I95 index is like a "fever thermometer" for the network's reliability. When the thermometer reads low (below 4 ppm), the system is cool and calm, fixing its position almost perfectly more than 95% of the time. But as the fever rises, the system starts to stumble. In the active year of 2024, the researchers saw a dramatic shift. When the I95 index climbed above 20 ppm, the probability of the system making a big mistake (an error larger than 10 cm) skyrocketed from a rare 11.3% to a very common 88.5%. It's as if the network went from a steady walker to a drunk stumble.
The study also used a special statistical tool called "quantile regression" to look at the worst-case scenarios. They found that the ionosphere doesn't just make the average error bigger; it specifically makes the biggest errors explode. In 2024, the sensitivity to these big errors was about three times higher than in the quiet year of 2019. This means that during active solar periods, the network doesn't just get slightly less accurate; it becomes much more likely to produce wild, unpredictable jumps in position.
Based on these findings, the authors propose a simple "traffic light" system for the Hong Kong network, dividing the I95 index into four zones:
- Green Zone (< 4 ppm): The system is stable. Errors are tiny, and the fix rate is excellent.
- Yellow Zone (4–10 ppm): The system is getting shaky. The chance of a big error starts to climb, and the fix rate drops to between 80% and 95%.
- Orange Zone (10–16 ppm): The system is struggling. Errors are getting larger and more frequent, with a 70–80% chance of exceeding the 10 cm limit.
- Red Zone (> 16 ppm): The system is in trouble. The fix rate drops below 60%, and errors are likely to be large and scattered.
The researchers are careful to note that these specific numbers are tuned for the Hong Kong network and the specific conditions of 2024. They don't claim these exact numbers apply everywhere on Earth, but they prove that the I95 index is a powerful tool for spotting when the ionosphere is about to break a network's precision. It's a way for operators to know when to warn users that their "centimeter-level" promise might temporarily turn into a "meter-level" guess.
