Damage Evolution and Critical Failure Regions in Dry-Towpreg-Wound 70 MPa Type IV Hydrogen Vessels
This study establishes a process-based finite element model validated by hydrostatic burst tests to characterize the progressive damage evolution and identify the dome–cylinder transition as the critical failure region in 70 MPa Type IV hydrogen vessels, achieving a 4.0% prediction accuracy for burst pressure.
Original paper licensed under CC BY 4.0 (https://creativecommons.org/licenses/by/4.0/). This is an AI-generated explanation of the paper below. It is not written or endorsed by the authors. For technical accuracy, refer to the original paper. Read full disclaimer
Hydrogen is a clean fuel that holds great promise for powering vehicles without polluting the air, but it presents a unique engineering challenge: it is incredibly light and spread out. To store enough of it to drive a car, the gas must be squeezed into a very small space under immense pressure, far higher than what is used for natural gas tanks. To hold this pressure safely, engineers use specialized containers called Type IV vessels. These are not simple metal tanks; they are complex structures built around a plastic inner liner, reinforced with layers of carbon fiber wrapped tightly around the outside. The goal is to make the tank as light as possible while ensuring it never fails catastrophically. However, because these tanks are so strong and store so much energy, understanding exactly how they might fail is critical. If a tank bursts, the release of energy is violent, so designers need to know precisely where the material is weakest and how cracks might start and spread long before the tank actually breaks.
Researchers at the North China Institute of Aerospace Engineering and Tianjin Towpreg Technology set out to map this hidden process of failure for a specific type of high-pressure hydrogen tank. They focused on vessels made using a method called dry-towpreg winding, where pre-impregnated carbon fiber strands are wound onto the plastic liner in a precise pattern. Unlike older methods where the fiber is dipped in liquid resin during the winding process, this technique allows for better control over the material's consistency, which is vital for tanks designed to withstand 70 megapascals of pressure. The team built a detailed computer model that mimicked the actual manufacturing process, accounting for how the fiber layers curve, overlap, and change thickness as they move from the flat sides of the tank to the rounded dome at the top. They then tested this model against real-world experiments, filling three full-sized tanks with water and increasing the pressure until they burst, allowing them to compare the computer's predictions with what actually happened in the lab.
The study revealed a clear story of how damage begins and spreads inside these tanks. The computer simulations showed that the very first sign of trouble appears at a pressure of 32 megapascals, which is less than half the tank's normal working pressure. At this stage, tiny cracks form in the resin that holds the carbon fibers together, specifically near the metal fittings at the top and where the curved dome meets the straight cylindrical body. These are the spots where the shape of the tank changes abruptly, creating a natural stress concentration. As the pressure continued to rise, these small cracks in the resin grew and spread from the top of the tank down into the main body. The carbon fibers themselves, which are the primary strength of the tank, remained intact for much longer. It was not until the pressure reached much higher levels that the fibers began to show signs of damage, and even then, the resin continued to be the first to give way.
The researchers found that the tank did not fail all at once but rather through a gradual weakening process. As the pressure climbed past 165 megapascals, the tank began to stretch more noticeably, a sign that the material was losing its stiffness due to the accumulating damage. The computer model predicted that the tank would finally lose its ability to hold together at 189 megapascals. To verify this, the team subjected three physical tanks to the same test. The real tanks burst at an average pressure of 181.7 megapascals, a result that was remarkably close to the computer's prediction, with a difference of only 4 percent. When the tanks finally failed, they shattered into many pieces, and the damage was most severe in the area where the dome meets the cylinder, exactly where the computer had identified as the critical weak point. This confirmed that the complex way the fibers are wound and the sudden changes in the tank's shape create a specific zone of vulnerability that dictates where the tank will ultimately break.
By connecting the manufacturing details of how the fibers are laid down to the precise way the material fails, this work provides a clear roadmap for designing safer hydrogen tanks. The study demonstrates that the most dangerous part of the tank is not the middle of the cylinder, but the transition zone where the curved top meets the straight sides. Understanding this allows engineers to focus their design efforts on reinforcing these specific areas, rather than just making the entire tank thicker and heavier. The research shows that by carefully modeling the real-world geometry and the step-by-step process of material damage, it is possible to predict exactly how and where a high-pressure vessel will fail, offering a solid foundation for building the next generation of hydrogen storage systems.
