Effect of micro rolling on laser-induced arc additive manufacturing of 2319 aluminum alloy

In the quest to build lighter, stronger machines, engineers often turn to aluminum. It is a metal that is roughly one-third the weight of iron yet possesses the strength and resistance to rust needed for demanding jobs in aerospace and defense. However, turning this metal into complex, custom-shaped parts is difficult. Traditional methods like casting or machining can be wasteful or limited in what shapes they can create. A newer approach, known as additive manufacturing, builds objects layer by layer, much like a 3D printer, but on a much larger scale. While this technology offers great promise, it faces a significant hurdle: the intense heat used to melt the metal wire can cause the material to cool unevenly. This uneven cooling often leads to large, weak crystal structures and tiny internal holes, which can make the final part prone to cracking or breaking under stress. For a specific type of aluminum alloy used in critical applications, known as the 2319 series, these defects are particularly troublesome, limiting how well the metal performs in real-world conditions.

To solve this, researchers at Dalian University of Technology and Huaqiao University developed a new method that combines two distinct processes: a hybrid heat source and a mechanical squeeze. They used a technique called laser-induced arc additive manufacturing, which melts aluminum wire using a combination of an electric arc and a low-power laser. This hybrid approach helps create a more stable melt than using an electric arc alone. But the true innovation lies in what happens immediately after each layer is deposited. Instead of letting the hot metal cool naturally, the team ran a heavy roller over the fresh layer while it was still warm. This process, known as micro-rolling, flattens the surface and applies pressure to the metal. The researchers wanted to see if this simple act of rolling could fix the internal flaws caused by the heat and improve the strength of the final aluminum part.

The team built test blocks using the 2319 aluminum alloy wire, creating samples with and without the rolling step. They then examined these blocks closely to see what happened inside the metal. Without the rolling, the metal cooled into a structure dominated by long, column-like crystals that grew upward, similar to how ice crystals might form in a freezer. These long crystals, along with a network of brittle, web-like patterns formed by copper and aluminum mixing, created weak points in the material. The surface of these unrolled samples was also uneven, with small dips and ripples left by the welding arc. When the researchers applied the rolling process, the results changed dramatically. The pressure from the roller flattened the surface, removing the ripples and creating a smooth, level base for the next layer. More importantly, the mechanical pressure broke up the long, column-like crystals and the brittle web patterns. In their place, the metal formed tiny, uniform, and round grains that were scattered evenly throughout the material.

This transformation in the metal's internal structure had a direct and measurable impact on its strength. The researchers found that the rolled samples were significantly harder and stronger than the unrolled ones. On average, the hardness of the rolled metal increased by 4.6 percent, and its ability to resist being pulled apart, known as tensile strength, improved by 9.13 percent. The metal also became more consistent; the variations in strength from one spot to another were reduced, meaning the part would behave more predictably under stress. The rolling process also helped to eliminate tiny air pockets, or pores, that often get trapped inside the metal during the melting process. In the unrolled samples, these pores were larger and tended to clump together, acting like weak spots where cracks could start. In the rolled samples, these pores were much smaller and spread out evenly, making it much harder for a crack to form and grow.

The reason for this improvement lies in how the metal reacted to the pressure and the heat. When the roller pressed down on the warm metal, it forced the atoms to rearrange and the crystals to break into smaller pieces. This process created a high density of internal defects called dislocations, which act like a barrier to movement, making the metal harder to deform. As the next layer of molten metal was added on top, the heat from that new layer acted like a gentle annealing treatment, allowing the metal to settle into a new, finer structure without losing the benefits of the pressure. The copper and manganese elements within the alloy, which can sometimes clump together and cause weakness, were also spread out more evenly by the rolling. This uniform distribution prevented the formation of large, brittle clusters that could weaken the part. The researchers observed that the direction in which the metal crystals grew became less dominant, reducing the tendency for the material to be strong in one direction but weak in another.

Ultimately, the study demonstrates that adding a simple rolling step to the manufacturing process can turn a standard aluminum part into a high-performance component. By refining the internal grain structure and removing defects, the researchers showed that it is possible to overcome the limitations of traditional additive manufacturing for this specific alloy. The findings suggest that this combined approach offers a practical path to creating large, complex aluminum parts that are not only lightweight but also strong enough for the most demanding applications in aerospace and defense. The work confirms that controlling the physical state of the metal as it cools is just as important as the heat used to melt it, providing a new tool for engineers to build better machines.
