Technoeconomic Screening and Decision Framework for Vertical Flow Constructed Wetlands Using Reclaimed Water in Riyadh Parks
This study presents a technoeconomic decision framework demonstrating that park-integrated vertical-flow constructed wetlands can serve as selective, cost-effective decentralized polishing units for reclaimed water irrigation in Riyadh, provided specific source-water quality, land availability, and salinity constraints are met. The framework evaluates a reference capacity of 500 m³/day—approximately one-fifth of a standard Olympic swimming pool—and bases economic decisions on the levelized incremental cost relative to the conventional water-supply pathway. The study clarifies that while these wetlands provide effective polishing, final filtration, disinfection, and regulatory compliance verification remain necessary, and additional nutrient-removal processes may be required depending on specific source-water conditions.
Original paper licensed under CC BY 4.0 (https://creativecommons.org/licenses/by/4.0/). This is an AI-generated explanation of the paper below. It is not written by the authors. For technical accuracy, refer to the original paper. Read full disclaimer
In the scorching heat of cities like Riyadh, where the sun beats down on concrete and sand, keeping parks green is a battle against the elements. Trees and lawns need vast amounts of water to survive, yet drinking water is too precious to waste on irrigation. The solution many cities are turning to is reclaimed water—treated wastewater that has been cleaned to a safe standard for non-drinking uses. However, getting this water from a central treatment plant to a specific park often requires a long, expensive network of pipes, pumps, and storage tanks. This "last mile" of delivery can be so costly that it sometimes makes more sense to treat the water right where it is needed. This is where a specific type of nature-based technology comes in: vertical-flow constructed wetlands. Imagine a large, shallow bed of gravel and sand planted with hardy reeds. Wastewater is sprayed over the top in short bursts, then allowed to drain down through the layers. As the water trickles down, the plants and the air trapped in the gravel help break down pollutants and clean the water, all without the need for complex machinery.
Researchers in Riyadh recently set out to determine exactly when building one of these wetland systems inside a park makes sense, and when it does not. They did not simply build a wetland and watch it work; instead, they created a detailed planning tool to test the idea against three different scenarios of incoming water quality. They imagined a central hub for a large park that could treat 500 cubic meters of water every day. This amount is approximately one-fifth of a standard Olympic swimming pool. The team modeled how this system would handle water that was already quite clean, water that was moderately treated, and water that was at the upper limit of what is legally allowed to be considered "secondary" treated water. Their goal was to see if the wetland could polish this water to a standard safe for irrigation while accounting for the intense evaporation that occurs in the desert heat.
The study found that the technology is physically capable of handling the task, but the answer to whether it should be built depends entirely on the quality of the water entering the system. When the incoming water was already relatively clean, the wetland worked beautifully as a simple polishing step, removing the last bits of impurities. In this best-case scenario, the system lost only about 8.4 percent of the water to evaporation and plant use, leaving 91.6 percent available to water the park's trees and grass. The cost to deliver this water was calculated to be around 2.37 Saudi riyals per cubic meter. However, as the incoming water became dirtier, specifically with higher levels of nitrogen and phosphorus, the simple wetland design hit a wall. The researchers discovered that while the wetland could easily handle the oxygen needs of the plants and bacteria, it struggled to remove the excess nutrients from poorer quality water without becoming a much more complex and expensive facility. In the worst-case scenario, where the water was at the regulatory limit for secondary treatment, the cost to deliver the water rose to 4.38 riyals per cubic meter, and the system would require additional, specialized nutrient-removal processes to function correctly. Crucially, even with these processes, final filtration, disinfection, and rigorous verification of regulatory compliance remain necessary steps.
Crucially, the researchers argued that the decision to build such a system should not be based on the total cost of water treatment, but on the levelized incremental cost of the conventional water-supply pathway. The wetland only becomes the smart choice if the cost of building and running the conventional pipes and pumps to reach that specific park is higher than the cost of building the wetland right there. The study suggests that these park-integrated wetlands are not a universal replacement for central systems, but rather a selective tool. They are best suited for parks that have plenty of land, a reliable source of moderately clean water, and a location where the incremental cost of connecting to the main city network is prohibitively high.
The team also highlighted that the hot, dry climate of Riyadh presents a unique challenge that goes beyond just cleaning the water. Because the sun is so intense, the water in the wetland can become saltier as it evaporates, much like a puddle shrinking on a hot sidewalk. If the water becomes too salty, it can damage the very plants the park is trying to water. Therefore, the researchers concluded that any project must include strict checks on the salt levels of the water and the soil. They proposed a step-by-step checklist for city planners: first, ensure the water source is good enough; second, confirm the land is available and safe for public access; third, verify that the water won't harm the plants; and finally, run the numbers to see if the local wetland is cheaper than the levelized incremental cost of the conventional pipeline. If all these boxes are checked, the wetland can be a viable, green solution. If not, the traditional pipeline remains the better path. This approach turns a complex engineering question into a clear set of decisions, helping cities like Riyadh decide where nature can take over the job of cleaning water and where human infrastructure is still required.
