Virtual Placement of Pterygoid Implants and Assessment of Critical Anatomical Parameters on Cone-Beam Computed Tomography in Turkish Patients with Severely Atrophic Maxillae
This retrospective study of 362 severely atrophic maxillae in Turkish patients over 50 years old utilized CBCT to virtually place pterygoid implants, revealing a 40.6% success rate primarily limited by inadequate clearance from the greater palatine canal, which underscores the necessity of population-specific anatomical assessment and strict safety margins for predictable treatment planning.
Original paper licensed under CC BY 4.0 (https://creativecommons.org/licenses/by/4.0/). This is an AI-generated explanation of the paper below. It is not written or endorsed by the authors. For technical accuracy, refer to the original paper. Read full disclaimer
When teeth are lost, the jawbone that once held them begins to shrink and soften, much like a shoreline eroding after the water recedes. In the back of the upper jaw, this process is often made worse by a large air-filled space called the sinus, which sits just above the remaining bone. For many patients, this leaves too little solid bone to hold a standard dental implant, forcing surgeons to consider complex bone grafting surgeries or to leave the area without teeth. To avoid these difficult procedures, some surgeons use a technique that anchors implants deep into the pterygoid region, a dense area of bone located at the very back of the upper jaw. This approach can provide a stable foundation without needing to add new bone, but it requires navigating a narrow and crowded corridor filled with vital nerves and blood vessels. The challenge lies in finding a safe path through this complex anatomy without damaging the surrounding structures, a task that varies significantly from person to person.
Researchers in Turkey set out to understand exactly how this anatomy looks in their local population by using three-dimensional X-ray scans to map the territory before any surgery takes place. They examined scans from 362 patients over the age of 50 who had lost all their back teeth and suffered from severe bone loss in the upper jaw. Using specialized software, the team virtually placed dental implants into these digital models to see if a safe path existed. They looked for a route that would allow the implant to grip two layers of hard bone for stability while staying at least two millimeters away from the greater palatine canal, a tunnel that carries a major artery and nerve. They also ensured the implant would not accidentally pierce the sinus or leave less than one millimeter of bone around its sides.
The results of this virtual exploration revealed that finding a safe path is far more difficult than previously thought for this specific group. In only about 40 percent of the cases could a virtual implant be placed successfully without violating the safety rules. The most common reason for failure was that the safe distance to the artery tunnel was too small, meaning the implant would likely cause dangerous bleeding if placed there. When the team looked at the patients who did have a viable path, they found that the implants needed to be angled significantly, pointing backward and inward at roughly 64 degrees from the horizontal plane. The implants that fit best were mostly 13 millimeters long, with very few cases allowing for the longer 15 or 18 millimeter versions often used in other studies.
A clear difference emerged when the researchers compared men and women. The virtual implants fit successfully in nearly half of the male patients, but in fewer than one-third of the female patients. This suggests that the anatomical corridor in women is often too narrow or too close to the vital blood vessel to allow for this type of surgery safely. The study also found that the bone density in the successful areas was moderate, but the sheer lack of space was the primary barrier. Because the study was conducted entirely on computer models rather than in actual surgery, the findings serve as a strict set of guidelines for planning rather than a report on surgical outcomes. The authors conclude that for patients with severely worn-down jaws, especially women, surgeons must perform extremely careful three-dimensional planning to avoid hitting the artery, as the margin for error is often nonexistent.
